H87H3-M4 USER MANUAL

Chapter 6

Memo

Содержание

Copyright 1
Disclaimer 1
Federal communications commission fcc 1
H87h3 m4 user manual 1
Preface 1
Trademark recognition 1
About the manual 2
Canadian department of communications 2
Declaration of conformity 2
H87h3 m4 user manual 2
Chapter 1 1 3
Chapter 2 9 3
Chapter 3 33 3
Connecting case components 7 3
H87h3 m4 user manual 3
Installing the motherboard 9 safety precautions installing the motherboard in a chassis checking jumper settings 0 installing hardware 1 3
Introducing the motherboard 1 introduction pakage contents specifications motherboard components i o ports 3
Preface i 3
Table of contents 3
Updating the bios 5 3
Using bios 33 about the setup utility 3 3
Using bios 4 3
Chapter 4 77 4
Chapter 5 81 4
Chapter 6 8 7 4
H87h3 m4 user manual 4
Chapter 1 5
Chapter 1 introducing the motherboard 5
H87h3 m4 user manual 5
Introduction 5
Package contents 5
Chapter 1 6
H87h3 m4 user manual 6
Specifications 6
Chapter 1 7
H87h3 m4 user manual 7
H87h3 m4 user manual 8
Chapter 1 9
H87h3 m4 user manual 9
Table of motherboard components 9
Chapter 1 10
H87h3 m4 user manual 10
I o ports 10
Chapter 1 11
H87h3 m4 user manual 11
H87h3 m4 user manual 12
1 safety precautions 13
2 installing the motherboard in a chassis 13
Chapter 2 13
Chapter 2 installing the motherboard 13
H87h3 m4 user manual 13
3 checking jumper settings 14
Chapter 2 14
H87h3 m4 user manual 14
4 1 installing the processor 15
4 installing hardware 15
Chapter 2 15
H87h3 m4 user manual 15
Chapter 2 16
H87h3 m4 user manual 16
4 2 installing the cpu cooler 17
Chapter 2 17
H87h3 m4 user manual 17
4 3 installing memory modules 18
Chapter 2 18
H87h3 m4 user manual 18
Chapter 2 19
Due to intel cpu spec definition please follow the table above for recommended memory configuration 19
For best performance and compatibility we recommend that users give priority to the white dimms ddr3_2 ddr3_4 when installing dimms 2 we suggest users not to mix memory type it is recommended to use the same brand and type memory on this motherboard 19
H87h3 m4 user manual 19
Recommend memory configuration 19
4 4 installing add on cards 20
Chapter 2 20
H87h3 m4 user manual 20
Chapter 2 21
H87h3 m4 user manual 21
4 5 connecting optional devices 22
Chapter 2 22
H87h3 m4 user manual 22
3 sata3_1 2 sata3 6 serial ata connectors 23
Chapter 2 23
H87h3 m4 user manual 23
Usb3f front panel usb 3 header 23
Case chassis intrusion detect header 24
Chapter 2 24
F_usb1 2 front panel usb 2 headers 24
H87h3 m4 user manual 24
Chapter 2 25
Cir consumer infrared header 25
H87h3 m4 user manual 25
Tpm trusted platform module header 25
Chapter 2 26
H87h3 m4 user manual 26
Lpt onboard parallel port header 26
Spdifo spdif out header 26
Ac 97 audio configuration to enable the front panel audio connector to support ac97 audio mode 27
Chapter 2 27
F_audio front panel audio header 27
H87h3 m4 user manual 27
Chapter 2 28
H87h3 m4 user manual 28
Chapter 2 29
Com onboard serial port header 29
H87h3 m4 user manual 29
Me_unlock me unlock header 29
4 6 installing a sata hard drive 30
About sata connectors 30
Chapter 2 30
H87h3 m4 user manual 30
Installing serial ata hard drives 30
4 7 connecting case components 31
After you have installed the motherboard into a case you can begin connecting the motherboard components refer to the following 31
Chapter 2 31
H87h3 m4 user manual 31
2 6 cpu_fan cpu cooling fan connector pwr_fan power cooling fan connector sys_fan system cooling fan connector 32
7 atx_power atx 24 pin power connector atx12v atx 12v power connector 32
Chapter 2 32
H87h3 m4 user manual 32
Chapter 2 33
Connecting 24 pin power cable 33
Connecting 4 pin power cable 33
H87h3 m4 user manual 33
Chapter 2 34
F_panel front panel header 34
H87h3 m4 user manual 34
Hard drive activity led 34
Power sleep message waiting led 34
Power switch 34
Reset switch 34
Chapter 2 35
H87h3 m4 user manual 35
Spk speaker header 35
H87h3 m4 user manual 36
About the setup utility 37
Chapter 3 37
Chapter 3 using bios 37
H87h3 m4 user manual 37
Chapter 3 38
H87h3 m4 user manual 38
Resetting the default cmos values 38
Using bios 38
Advanced 39
Bios navigation keys 39
Chapter 3 39
Default 39
H87h3 m4 user manual 39
Language 39
Chapter 3 40
H87h3 m4 user manual 40
Main menu 40
System date time the date and time items show the current date and time on the computer if you are running a windows os these items are automatically updated whenever you make changes to the windows date and time properties utility 40
System language english this item is used to set system language 40
This menu shows the information of bios and enables you to set the system language date and time 40
Advanced menu 41
Chapter 3 41
H87h3 m4 user manual 41
The advanced menu items allow you to change the settings for the cpu and other system 41
Chapter 3 42
H87h3 m4 user manual 42
Lan configuration 42
Onboard lan controller enabled use these items to enable or disable onboard lan controller 42
The item in the menu shows the lan related information that the bios automatically detects 42
To return to the advanced menu page 42
Chapter 3 43
Cpu system power smart fan control enabled 43
H87h3 m4 user manual 43
On motherboards support hardware monitoring this item lets you monitor the parameters for critical voltages temperatures and fan speeds 43
Pc health status 43
These items enable you to define the cpu system power by smartly adjusting the cpu system power fan when it is set at certain temperature the cpu system power fan pwm value will change accordingly 43
To view the following screen smart fan function 43
Chapter 3 44
H87h3 m4 user manual 44
An input signal on the serial ring indicator ri line in other words an incoming call on the modem awakens the system from a soft off state 45
Chapter 3 45
Eup function enabled this item allows user to enable or disable eup support 45
H87h3 m4 user manual 45
Power led type dual color led this item shows the type of the power led 45
Power management setup 45
Resume by pme disabled this item specify whether the system will be awakened from power saving modes when activity or input signal of the specified hardware peripheral or components is detected 45
Resume by ps2 kb disabled this item enables or disables you to allow keyboard activity to awaken the system from power saving mode 45
Resume by ps2 ms disabled this item enables or disables you to allow mouse activity to awaken the system from power saving mode 45
Resume by ring disabled 45
Resume by rtc alarm disabled the system can be turned off with a software command if you enable this item the system can automatically resume at a fixed time based on the system s rtc realtimeclock use the items below this one to set the date and time of the wake up alarm you must use an atx power supply in order to use this feature 45
Resume by usb disabled this item allows you to enable or disable the usb device wakeup function from s3 mode 45
This page sets up some parameters for system power management operation 45
To return to the advanced menu page 45
Chapter 3 46
H87h3 m4 user manual 46
Pci express 16x speed auto this item allows user to configure the pci express 16x speed 46
Pci express configuration 46
The item in the menu shows the information of pci express configuration 46
To return to the advanced menu page 46
Acpi settings 47
Acpi sleep state s3 suspend to ram this item allows user to enter the acpi s3 suspend to ram sleep state default 47
Chapter 3 47
H87h3 m4 user manual 47
The item in the menu shows the highest acpi sleep state when the system enters suspend 47
To return to the advanced menu page 47
Active processor cores all use this item to control the number of active processor cores 48
Chapter 3 48
Cpu configuration 48
H87h3 m4 user manual 48
Hyper threading enabled this item is only available when the chipset supports hyper threading and you are using a hyper threading cpu 48
Intel r core tm i7 4770k cpu 3 0ghz this is display only field and displays the information of the cpu installed in your computer em64t supported this item shows the computer supports em64t processor speed 3500mhz this item shows the current processor speed processor stepping 306c3 this item shows the processor stepping version microcode revision 8 this item shows the microcode version processor cores 4 this item shows the core number of the processor intel ht technology supported this item shows the computer not supports intel ht technology 48
Intel vt x technology supported this item shows the computer supports intel vt x technology 48
The item in the menu shows the cpu configuration 48
Chapter 3 49
H87h3 m4 user manual 49
Chapter 3 50
H87h3 m4 user manual 50
Sata configuration 50
Sata mode ahci mode use this item to select sata mode 50
Sata port 1 6 this motherboard supports six sata channels and each channel allows one sata device to be installed use these items to configure each device on the sata channel 50
To return to the advanced menu page 50
Use this item to show the mode of serial sata configuration options 50
Chapter 3 51
H87h3 m4 user manual 51
To return to the advanced menu page 51
Tpm support enabled use this item to enable or disable the tpm port o s will not show tpm reset of platform is required 51
Trusted computing 51
Use this item to show the information of trused computing configuration 51
All usb devices enabled use this item to enable or disable all usb devices 52
Chapter 3 52
H87h3 m4 user manual 52
Legacy usb support enabled use this item to enable or disable support for legacy usb devices 52
To return to the advanced menu page 52
Usb configuration 52
Use this item to show the information of usb configuration 52
Change settings auto 53
Chapter 3 53
H87h3 m4 user manual 53
Serial port enabled 53
Super io chip it8728 this item shows the information of the super io chip 53
Super io configuration 53
This item allows you to enable or disable serial port device settings io 3f8h irq 4 53
This item shows the information of the device settings 53
To return to the super io configuration page 53
To view the following screen 53
Use this item to change device settings 53
Use this item to show the information of super io configuration 53
Change settings auto 54
Chapter 3 54
Device mode ecp mode 54
H87h3 m4 user manual 54
Parallel port enabled 54
This item allows you to enable or disable parallel port device settings io 378h irq 4 dma 3 54
This item shows the information of the device mode 54
This item shows the information of the device settings 54
To return to the super io configuration page 54
To view the following screen 54
Use this item to change device settings 54
Chapter 3 55
Cir controller enabled 55
H87h3 m4 user manual 55
This item allows you to enable or disable cir controller 55
To return to the super io configuration page 55
To view the following screen 55
Chapter 3 56
H87h3 m4 user manual 56
Intel r rapid start technology 56
Intel r rapid start technology disabled use this item to enable or disable the intel r rapid start technology 56
To return to the advanced menu page 56
Use this item to show the information of intel r rapid start technology 56
Chapter 3 57
H87h3 m4 user manual 57
Intel r smart connect technology 57
Isct support disabled use this item to enable or disable isct support 57
To return to the advanced menu page 57
Use this item to show the information of intel r smart connect technology 57
Bios hotkey pressed disabled use this item to enable or disable the bios hotkey pressed 58
Chapter 3 58
H87h3 m4 user manual 58
Intel amt disabled use this item to enable or disable the intel active management technology intel amt function 58
Intel me bios extension configuration 58
Mebx selection screen disabled use this item to enable or disable the mebx selection screen 58
To return to the advanced menu page 58
Use this item to show the information of intel me bios extension configuration 58
Chapter 3 59
Chipset menu 59
Dvmt memory 256m 59
H87h3 m4 user manual 59
Igd memory 64m 59
Igd multi monitor disabled 59
System agent configuration 59
The chipset menu items allow you to change the settings for the north bridge chipset south bridge chipset and other system 59
This item allows you to enable or disable the igd multi monitor 59
This item shows the information of the igd internal graphics device memory 59
To view the following screen 59
When set to fixed mode the graphics driver will reserve a fixed position of the system memory as graphics memory according to system and graphics requirements 59
Chapter 3 60
H87h3 m4 user manual 60
Chapter 3 61
H87h3 m4 user manual 61
Multi monitor technology 61
Chapter 3 62
H87h3 m4 user manual 62
Step 2 install all the drivers of pci express graphic cards click the browse cd item then appears the following screen select the driver you want to install e g nvidia geforce 8400 gs microsoft corporation wddm v1 and double click it 62
Step 3 enable igd multi monitor from bios in the following bios screen please set igd multi monitor to enabled 62
Chapter 3 63
Display devices 63
Enter the control panel menu select the display in the all control panel items and click the screen resolution then appears the following screen 63
H87h3 m4 user manual 63
Select display devices set the multiple displays option and to extend destop for display multi monitor technology 63
Set the multiple displays 63
Show the path of the setting location 63
Step 4 change the appearance of your displays under windows 7 8 63
The type of the display 63
Chapter 3 64
H87h3 m4 user manual 64
Chapter 3 65
H87h3 m4 user manual 65
Pch configuration 65
Restore ac power loss power off 65
This item enables or disables azalia hd audio case open warning disabled 65
This item enables or disables the warning if the case is opened up and the item below indicates the current status of the case chassis opened no 65
This item enables your computer to automatically restart or return to its operating status azalia hd audio enabled 65
This item indicates whether the case has been opened 65
To return to the chipset menu page 65
To view the following screen 65
Chapter 3 66
H87h3 m4 user manual 66
Me configuration 66
Me control enabled use this item to enable or disable the me firmware 66
Me fw version 9 347 this item shows the me fw version 66
To return to the chipset menu page 66
To view the following screen 66
Chapter 3 67
Cpu overclocking configuration 67
Cpu ratio 35 67
H87h3 m4 user manual 67
M i b iii mb intelligent bios iii menu 67
Scroll to this item to view the following screen 67
This item allows you to control non turbo cpu ratio 67
This page enables you to set the clock speed and system bus for your system the clock speed and system bus are determined by the kind of processor you have installed in your system 67
Chapter 3 68
H87h3 m4 user manual 68
Chapter 3 69
Graphics core ratio limit 25 this item allows you to control the internal gfx core ratio 69
H87h3 m4 user manual 69
North bridge configuration 69
Scroll to this item to view the following screen 69
To return to the m i b iii menu page 69
Chapter 3 70
H87h3 m4 user manual 70
Memory configuration 70
Scroll to this item to view the following screen 70
Chapter 3 71
Dll weak lock support enabled this item allows you to enable or disable the dll weak lock support 71
Enh interleave support enabled this item allows you to enable or disable the enh interleave support 71
H87h3 m4 user manual 71
Mc lock enabled this item allows you to enable or disable capacity to lock mc registers or not 71
Memory frequency 1333 mhz this item shows the information of the memory frequency 71
Memory frequency 1333 this item shows the memory frequency 71
Memory profiles automatic this item enables you to set the memory profiles the selection of memory profiles impacts memory sizing behavior 71
Memory rc version 1 this item shows the information of the memory rc version 71
Ri support enabled this item allows you to enable or disable the rank interleave support note ri and hori can not be enabled at the same time 71
Total memory 8192 mb ddr3 this item shows the information of the total memory 71
Chapter 3 72
H87h3 m4 user manual 72
Ch0writevref 0 60 v auto this item allows you to adjust the ch0writevref from 0 to 108 and the default is 54 1 step is 4mv 73
Ch1writevref 0 56 v auto this item allows you to adjust the ch1writevref from 0 to 108 and the default is 54 1 step is 4mv 73
Chapter 3 73
Chvrefca 0 56 v auto this item allows you to adjust the chvrefca from 0 to 108 and the default is 54 1 step is 4mv 73
Dimm voltage 1 12 v auto this item allows you to adjust the dimm voltage 73
H87h3 m4 user manual 73
Over voltage configuration 73
Processor input voltage 1 52 v auto this item allows you to adjust the processor input voltage 73
Scroll to this item to view the following screen 73
Chapter 3 74
H87h3 m4 user manual 74
Chapter 3 75
H87h3 m4 user manual 75
Boot menu 76
Chapter 3 76
H87h3 m4 user manual 76
This page enables you to set the keyboard numlock state 76
To see the submenu 76
Administrator password status not install this item shows administrator password installed or not 77
Chapter 3 77
H87h3 m4 user manual 77
Platform mode setup this item allows you to set the platform mode 77
Secure boot disabled this item is used to control the secure boot flow it is possible only if system runs in user mode 77
Security menu 77
This page enables you to set setup administrator password and user password 77
To setup the administrator password 77
User password status not install this item shows user password installed or not 77
Boot override use this item to select the boot device 78
Chapter 3 78
Discard changes and exit this item enables you to exit system setup without saving any changes 78
Discard changes and reset this item enables you to reset system setup without saving any changes 78
Exit menu 78
H87h3 m4 user manual 78
Save as user defaults this item enables you to save the changes that you have made as user defaults restore user defaults this item enables you to restore the user defaults 78
Save changes and exit this item enables you to exi 78
Save changes and reset this item enables you to reset system setup after saving the changes 78
Save options this item enables you to save the options that you have made save changes this item enables you to save the changes that you have made discard changes this item enables you to discard any changes that you have made restore defaults this item enables you to restore defaults to all the setup options 78
The system setup after saving the changes 78
This page enables you to exit system setup after saving or without saving the changes 78
Chapter 3 79
H87h3 m4 user manual 79
Updating the bios 79
H87h3 m4 user manual 80
Auto installing under windows 7 8 81
Chapter 4 81
Chapter 4 using the motherboard software 81
H87h3 m4 user manual 81
Chapter 4 82
Drivers and software are automatically installed in sequence follow the onscreen instructions confirm commands and allow the computer to re start a few times to complete the installation 82
H87h3 m4 user manual 82
Windows 8 will show the following screen after system restart you must select desktop in the bottom left to install the next driver 82
Chapter 4 83
Ecs utility software intelligent ez utility 83
H87h3 m4 user manual 83
Manual installation 83
Chapter 4 84
H87h3 m4 user manual 84
Before creating a raid set 85
Chapter 5 85
H87h3 m4 user manual 85
Matrix storage manager raid configuration 85
Chapter 5 86
Entering inte 86
H87h3 m4 user manual 86
Matrix storage manager raid bios utility 86
Chapter 5 87
Creating a raid set 87
H87h3 m4 user manual 87
Chapter 5 88
Deletes all the data in the hdds 88
H87h3 m4 user manual 88
The following screen appears displaying the relevant information about the raid set you created 88
Users please be noted that raid 0 stripe is set to accelerate the data access and raid 1 mirror is set to provide the data backup if you want to set raid 0 you need to set the 2nd boot device item in the bios to intel volume0 see section advanced setup for details 88
Chapter 5 89
Deletes all the data in the hdds 89
Deleting a raid set 89
H87h3 m4 user manual 89
Chapter 5 90
Deletes all the data in the hdds 90
Exiting setup 90
H87h3 m4 user manual 90
Resetting disks to non raid 90
To reset disks to non raid 90
Chapter 6 91
Chapter 6 trouble shooting 91
H87h3 m4 user manual 91
Start up problems during assembly 91
Chapter 6 92
H87h3 m4 user manual 92
Maintenance and care tips 92
Start up problems after prolong use 92
Basic troubleshooting flowchart 93
S e y s e y 93
Chapter 6 94
H87h3 m4 user manual 94

ECS Elitegroup H87H3-M4 [94/94] H87h3 m4 user manual

Содержание

Похожие устройства
