Chapter 3

Z87H3-A4 USER MANUAL

Main Advanced Chipset M.I.B. III Boot Security Exit

+/- : Change Opt.

Enter/Dbl Click : Select

: Select Screen

/Click: Select Item

F1: General Help

F2: Previous Values

F3: Optimized Defaults

F4: Save & Exit

ESC/Right Click: Exit

Graphics Core Ratio Limit

Intel Graphics Configuration

Graphics Core Ratio Limit 16

Graphics Core Ratio Limit (16)

This item allows you to control the internal GFX core ratio.

Press <Esc> to return to the M.I.B. III Menu page.



North Bridge Configuration

Scroll to this item to view the following screen:
