Multi-Language Translation
Português
I/O Integrado
A motherboard possui um conjunto completo de portas I/O e conectores:
• Duas portas PS/2 para rato e teclado
• Uma porta paralela com cabo
• Uma porta de série
• Quatro portas USB
• Uma porta LAN (opcional)
• Fichas áudio para entrada de microfone, entrada e saída de Áudio 8-ch
Microprogramação BIOS
Esta motherboard usa AWARD BIOS que permitem aos utilizadores configurar muitas
características do sistema incluindo as seguintes:
• Gestão de corrente
• Alarmes de despertar
• Parâmetros CPU
• Temporização de memória e CPU
A microprogramação poderá ser também usada para estabelecer parâmetros para diferentes
velocidades de relógio do processador.
Algumas especificações de hardware e itens de software poderão ser sujeitos a
alteraçõessem aviso prévio.
A motherboard suporta um domínio bus UltraDMA bus com taxas de Transferência de
133/100/66/33 MB/s.
A motherboard é fornecida com as seguintes opções de expansão:
• Duas PCI Express x16 para Interface de Gráficos
• Duas ranhuras 1 x PCI Express
• Duas ranhuras compatíveis com PCI v2.3 de 32 bits
• Duas conectores IDE 40 pinos, que suportam até quatro dispositivos IDE
• Um interface com drive de disco flexível
• Quatro conectores SATA de 7 pin
Opções de Expansão
Áudio
• Compatível com AC’97 v2.3 CODEC
• Suporta CODEC áudio com 6 canais concebido para sistemas
multimédia para PC
• Fornece três entradas estéreo nível de linha analógicas com controlo de
volume de 5 bits: LIne-in, CD, AUX
• Cumpre com os requisitos áudio WHQL/WLP 2.0 da Microsoft audio
• Compatível com Alta Definição Áudio da Intel, suportando DACs com 8
canais com rácio 95dB S/N
• Compatibilidades: 192/96/48/44.1 KHz com 24/20/16 bits
• Suporte de alimentação: Digital: 3.3V; Analógico: 3.3V/5.0V
• Todas as fichas analógicas são entradas estéreo e redistribuição de saídas
para ligar & reproduzir analógico
• Cumpre com os requisitos áudio WHQL/WLP 2.0 da Microsoft.
• Compatível com Direct Sound 3D
TM
• Saída Descodificador Digital Dolby para aplicação electrónica de
consumo
Esta motherboard pode suportar qualquer um dos seguintes conjuntos de chips Áudio.
