ECS Elitegroup RD480-A939 [83/92] A firewire opcjonalnie
![ECS Elitegroup RD480-A939 [83/92] A firewire opcjonalnie](/views2/1212432/page83/bg53.png)
Multi-Language Translation
Polski
Mostek północny (NB) RD480 i mostek południowy (SB) SB450 chipsetu oparty jest na
nowatorskiej i skalowalnej architekturze o sprawdzonej niezawodności i funkcjonalnoœci.
Pamięć
• DDR 400/333/266 DDR SDRAM z obsługą dwu kanałów
• Przystosowana do obsługi cztery banków niebuforowanej pamięci DIMM o
pojemności do 4 GB.
Chipset
• 1 złącze x2 (rozszerzalne do x4) A-Link Express (zgodne ze stan-
dardem PCI Express 1.0a) służące do podłączenia ATI IXP
• Obsługuje jedno graficzne złącze PCI Express x16, w pełni zgodne
ze standardem PCI Express Base w wersji 1.0a.
• Obsługuje pojedyncze układy wykonane w technologii CMOS 0.13
mikrona, 1.0-1.2v
Cechy
Procesor
Ta płyta główna zaopatrzona jest w podstawkę dla procesorów z 939 nóżkami i charakteryzuje
się następującymi cechami:
• Obsługuje procesory firmy AMD typu Sempron/Athlon64/Athlon 64 FX/
Athlon64 X2
• Obsługuje złącze HyperTransport
TM
(HT) z szybkością do 2000MT/s
Technologia HiperTransportu
TM
jest protokołem komunikacji między dwoma urządzeniami,
który umożliwia układom zcalonym wymieniać informację z dużo większymi szybkościami
niż dotychczas stosowane technologie wzajemnych połączeń.
• Interfejs 2/4-lane A-Link Express (zgodny z PCI Express w wersji
1.0a) dla RADEON IGP
• Zgodne ze standardem PCI w wersji 2.3 obslugujące do 7 urządzeń
bus master
• Obslugująca cztery urządzenia Serial ATA, zgodne ze standardem
Serial ATA wersja 1.0
• Zintegrowany kontroler USB 2.0 obslugujący do do ośmiu gniazd
USB 2.0
• Zintegrowany kontroler IDE obsługujący tryby pracy Ultra DMA
133/100/66/33
RD480 (NB)
SB450 (SB)
Zintegrowana obsługa sieci LAN (opcjonalnie)
Zintegrowana obsługa sieci LAN posiada następujące właściwości:
• Obsluguje N-drożne automatycznie ustalane operacje z szybkościami 100/
10Mb/s
• Zdolność Half/Full duplex
• Obsługuje funkcję Wake-On-LAN i zdalnie sterowane wake-up
(uruchamianie komputera)
• Zintegrowany terminal nadawczo-odbiórczy 10/100/1000
• Obsluguje 32 bitowe PCI w wersji 2.3 o częstotliwościach 33/66-MHz
• Całkowicie zgodny z IEEE802.3, IEEE802.3u and IEEE802.3ab
1394a FireWire (opcjonalnie)
• W pełni zgodna z zabezpieczeniem standardu IEEE 1394-1995 dla wysokiej
wydajności szyny szeregowej oraz standardu IEEE 1394a-2000
• Dwa złącza całkowicie zgodne ze standardem IEEE 1394a-2000 o szybkości
przesyłania 100/200/400 Mb/s
