2
Feature
Processor
The motherboard uses an 939-pin socket that carries the following features:
• Accommodates AMD Sempron/Athlon 64/Athlon 64 FX/Athlon 64 X2 pro-
cessors
• Supports up to 2000MT/s HyperTransport
TM
(HT) interface speeds
HyperTransport
TM
Technology is a point-to-point link between two devices, it enables
integrated circuits to exchange information at much higher speeds than currently
available interconnect technologies.
Chipset
The RD480 Northbridge (NB) and SB450 Southbridge (SB) chipsets are based on an
innovative and scalable architecture with proven reliability and performance.
RD480 (NB) • 1 x 2 (expandable to x 4) A-Link Express interface (PCI
Express 1.0a compliant) for connection to the ATI IXP
• Supports one PCI Express x16 for Graphics Interface, fully
compliant to the PCI Express Base Specification revision
1.0a.
• Supports Single chip solution in 0.13 micron, 1.0-1.2v CMOS
technology
SB450 (SB)
• 2/4-lane A-Link Express interface (PCI Express 1.0a com-
pliant) to RADEON IGPs
• Compliant with PCI 2.3 specification, up to 7 bus master
devices supported
• Four Serial ATA devices supported, compliant with Serial
ATA 1.0 specification
• Integrated USB 2.0 Host Controller supporting up to eight
USB 2.0 ports
• Integrated IDE controller supports Ultra DMA 133/100/66/33
modes
Memory
• DDR 400/333/266 DDR SDRAM with Dual Channel supported
• Accommodates four unbuffered DIMMs, up to 4 GB maximum memory size
Onboard LAN (Optional)
This motherboard may support either of the following LAN feature:
•
•
•
Supports 100/10 Mb/s N-Way Auto negotiation operation
Half/Full duplex capability
Supports Wake-On-LAN(WOL) function and remote wake-up
•
•
•
Integrate 10/100/1000 transceiver
Supports PCI v2.3, 32-bit, 33/66MHz
Supports fully with IEEE802.3, IEEE802.3u and IEEE802.3ab
1394 FireWire (Optional)
• Fully compliant with provisions of IEEE Std 1394-1995 for a high-performance
serial bus and IEEE Std 1394a-2000
• Two IEEE Std 1394a-2000 fully compliant cable ports at 100/200/400 Mb/s
Introducing the Motherboard
