Installing the Motherboard
CPU_FAN/SYS_FAN/PWR_FAN: FAN Power Connectors
1 GND Ground
2 +12V Power +12V
3
FAN RPM rate sense Sensor
Pin Signal Name Function
ATX_POWER: ATX 20-pin Power Connector
1 +3.3V 11 +3.3V
2 +3.3V 12 -12V
10 +12V 20 +5V
3 Ground 13 Ground
4 +5V 14 PS ON#
5 Ground 15 Ground
6 +5V 16 Ground
7 Ground 17 Ground
8 PW_OK 18 -5V
9 Standby Voltage +5V 19 +5V
Pin Signal Name Pin Signal Name
ATX12V: ATX 12V Power Connector
4 Ground
3 Ground
2 +12V
1 +12V
Pin Signal Name
