35
Using BIOS
Primary/Secondary Master/Slave UltraDMA (Auto)
Each IDE channel supports a master device and a slave device. This motherboard supports
UltraDMA technology, which provides faster access to IDE devices.
If you install a device that supports UltraDMA, change the appropriate item on this list to
Auto. You may have to install the UltraDMA driver supplied with this motherboard in order
to use an UltraDMA device.
IDE Prefetch Mode (Enabled)
The onboard IDE drive interfaces supports IDE prefetching, for faster drive access. If you
install a primary and secondary add-on IDE interface, set this field to Disabled if the
interface does not support prefetching.
IDE DMA transfer access (Enabled)
This item allows you to enable the transfer access of the IDE DMA then burst onto the PCI
bus and nonburstable transactions do not.
Serial-ATA (Enabled)
This item allows you to enable or disable the onboard Serial-ATA device.
SATA DMA transfer (Enabled)
This item allows you to enable or disable the function of DMA transfer with the onboard
Serial-ATA device.
Press <Esc> to return to the Advanced Chipset Features page.
Phoenix-AwardBIOS CMOS Setup Utility
IDE Function Setup
RAID Config (Press Enter)
Scroll to this item and press <Enter> to view the following screen:
Item Help
Menu Level
IDE RAID [Disabled]
PATA Channel0 Master RAID Disabled
PATA Channel0 Slave RAID Disabled
PATA Channel1 Master RAID Disabled
PATA Channel1 Slave RAID Disabled
SATA Primary Master RAID Disabled
SATA Secondary Master RAID Disabled
F5:Previous Values F7:Optimized Defaults
: Move Enter: Select +/-/PU/PD:Value F10:Save ESC:Exit F1: General Help
IDE RAID (Disabled)
This item allows you to enable or disable the onboard RAID function of RAID supporting
devices.
• IDE Channel0/1 Master/Slave RAID (Disabled): These four items enable
or disable the IDE Primary/Secondary RAID.
• SATA Primary/Secondary Master RAID (Disabled): These two items
enable or disable the SATA Primary/Secondary RAID.
Press <Esc> to return to the Advanced Chipset Features page.
