ECS Elitegroup A75F-M [11/76] Introducing the motherboard
![ECS Elitegroup A75F-M [11/76] Introducing the motherboard](/views2/1212459/page11/bgb.png)
7
Introducing the Motherboard
Table of Motherboard Components
This concludes Chapter 1. The next chapter explains how to install the motherboard.
LABEL COMPONENTS
1. CPU Socket Socket FM1 for AMD Llano processors
2. SYS_FAN System cooling fan connector
3. CPU_FAN CPU cooling fan connector
4. DDR3_1~4 240-pin DDR3 SDRAM slots
5. ATX_POWER Standard 24-pin ATX power connector
6. SPK Speaker header
7. SATA1~6 Serial ATA 6.0 Gb/s connectors
8. F_PANEL Front panel switch/LED header
9. F_USB1
Front panel USB 2.0 header（with EZ Charger function）
10. F_USB2~3 Front panel USB 2.0 headers
11. USB3F Front panel USB 3.0 header
12. LPT Onboard parallel port header
13. COM Onboard serial port header
14. F_1394A Onboard 1394a header
15. SPDIFO SPDIF out header
16. CLR_CMOS Clear CMOS jumper
17. CASE Case Open header
18. PCI1~2 32-bit add-on card slots
19. PCIE1 PCI Express x1 slot
20. PCIEX16 PCI Express slot for graphics interface
21. F_AUDIO Front panel audio header
22. ATX12V 4-pin +12V power connector
