Introducing the Motherboard
Audio
• 7.1+2 Channel High Definition Audio Codec
• Meets Microsoft WLP3.x (Windows Logo Program) audio requirements
• All DACs supports 44.1k/48k/96k/192kHz sample rate
• Software selectable 2.5V/3.2V/4.0V VREFOUT
• Direct Sound 3D
TM
compatible
• Power Support: Digital: 3.3V; Analog: 5.0V
Feature
Processor
• Accommodates AMD Llano processors
• Supports CPU up to 100W TDP
This motherboard uses a socket FM1 that carries the following features:
The AMD A75 (Hudson D3) chipset is based on an innovative and scalable
architecture with proven reliability and performance.
Chipset
Memory
• Supports 1866/1600/1333 DDR3 SDRAM with Dual-channel architec-
ture
• Accommodates four unbuffered DIMMs
• Up to 16 GB per DIMM with maximum memory size up to 64 GB
• Supports one PCI-Express x16 Gen2 slot
• Supports one PCI Express x1 slot
• Compliant with PCI 2.3 specification at 33 MHz
• Supports six Serial ATA devices which speeds up to 6 Gb/s
• Integrated USB 3.0 Host Controller supporting up to four USB 3.0 ports
• Integrated USB 2.0 Host Controller supporting up to ten USB 2.0 ports
• Supports integrated RAID 0,1 and RAID 10 functionality across all 6
ports (RAID 10 requires use of 4 or more SATA ports)
• Supports ACPI states S3, S4 and S5
Onboard LAN (Optional)
The onboard LAN provides the following features:
• Supports PCI Express
TM
1.1
• Integrated 10/100/1000 transceiver
• Wake-on-LAN and remote wake-up support
• Supports PCI Express
TM
1.1
• Integrated 10/100 transceiver
• Wake-on-LAN and remote wake-up support
