ECS Elitegroup A75F-M [8/76] Introducing the motherboard
![ECS Elitegroup A75F-M [8/76] Introducing the motherboard](/views2/1212459/page8/bg8.png)
4
Introducing the Motherboard
• AMD A75 (Hudson D3)
• FM1 for AMD Llano processors
• Supports CPU up to 100W TDP
• Dual-channel DDR3 memory architecture
• 4 x 240-pin DDR3 DIMM sockets support up to 64 GB
• Supports 1866/1600/1333 DDR3 SDRAM
• 1 x PCI Express Gen2 x16 slot
• 1 x PCI Express x1 slot
• 2 x PCI slots
• Supported by AMD A75 (Hudson D3)
-6 x Serial ATA 6.0 Gb/s Host Controllers
• ALC892 8-Ch High Definition audio CODEC
• Compliant with HD audio specification
• Realtek 8111E VL Gigabit Lan (co-lay Realtek 8105E VL 10/
100 LAN)
• 1 x D-sub (VGA) port
• 1 x HDMI port
• 1 x PS/2 keyboard and mouse combo connector
• 4 x USB 2.0 ports
• 2 x USB 3.0 blue ports
• 1 x RJ45 LAN port
• 1 x DVI Port
• 1 x optical SPDIFO port and audio jacks for microphone, line-
in and 8-ch line-out
• 1 x 24-pin ATX Power Supply connector
• 1 x 4-pin ATX Power Supply connector
• 1 x 4-pin CPU_FAN connector
• 1 x 3-pin SYS_FAN connector
• 3 x USB 2.0 headers support additional 6 USB 2.0 ports
(F_USB1 supports EZ charger)
• 1 x USB 3.0 header support additional 2 USB 3.0 ports
• 6 x Serial ATA 6Gb/s connectors
• 1 x COM header
• 1 x LPT header
• 1 x 1394 header (Optional)
• 1 x Case Open header
• 1 x Clear CMOS header
• 1 x Front panel audio header
• 1 x Speaker header
• 1 x SPI_DEBUG header
• 1 x Front panel switch/LED header
• 1 x SPDIF out header
Chipset
Memory
Expansion
Slots
Storage
Audio
LAN
Rear Panel I/O
Internal I/O
Connectors &
Headers
CPU
Specifications
