Chapter 2

H61H2-TI USER MANUAL

No. Components

1LCD_SEL

2CLR_CMOS

3ME_DIS

This section explains how to set jumpers for correct configuration of the

motherboard.

2-3. Checking Jumper Settings

1. LCD_SEL: LCD select jumper (optional)

1.When your panel connects to LVDS, please check LCD Select header setting

first.

2.Due to the differences of the panel parameters, please follow the above

illustration to place the jumper caps.
