Z77H2-AX USER MANUAL
Chapter 1
7. Audio Ports
Use the audio jack to connect audio devices. The C port is for stereo line-in
signal, while the E port is for microphone in signal. This motherboard supports
audio devices that correspond to the A, B, and D port respectively. In addition,
both of the 2 ports, B, and D provide user with both right & left channels
individually. Users please refer to the following note for specific port funtion
definition.
8. Optical SPIDF Output
This jack connects to external optical digital audio output devices.
9. USB 3.0 Ports
Use the USB 3.0 ports to connect USB 3.0 devices.
10. USB 2.0 Ports
Use the USB 2.0 ports to connect USB 2.0 devices.
11. eSATA 6Gb/s Ports
Use this port to connect to external SATA boxes or Serial ATA port multipliers.
The above port definition can be changed to audio input or audio output by
changing the driver utility setting.
A: Cente r & Woofer D: Front Out
B: Back Surround E: Mic_in Rear
C: Line-in -
