Z77H2-AX USER MANUAL

Chapter 1

• AMI BIOS with 64Mb SPI Flash ROM

- Supports ECS M.I.B X Utility

- Supports Plug and Play

- Supports ACPI & DMI

- Supports S1 / STR (S3) /STD (S4)

- Supports FSB adjustment, increase in a increase of 1/100

MHz

- Supports Hardware monitor

- Audio, LAN, can be disabled in BIOS

- F7 hot key for boot up devices option

- Supports Over-Clocking

System BIOS

Form Factor • ATX Size, 305mm x 244mm

• 1 x Front Panel audio header

• 1 x debug post

• 1 x power on button

• 1 x reset button

• 1 x mSATA connector

- Supports eBLU/eOC/eDLU/eSF

AP Support
