Chapter 1
2
Z77H2-AX USER MANUAL
CPU
Specifications
• Intel
®
Z77 ChipsetChipset
• Dual-channel DDR3 memory architecture
• 4 x 240-pin DDR3 DIMM sockets support up to 32 GB
• Supports DDR3 2400(OC)+/1600/1333/1066 MHz DDR3
SDRAM
Memory
• 3 x PCI Express x16 slots
(The PCI Express x16 slots conform to PCI Express 3.0 Standard)
• 2 x PCI Express x1 Gen2 slots
• 2 x PCI slots
• Supported by Intel
®
Z77 Express Chipset and Asmedia
ASM1061
- 2 x Serial ATA 3Gb/s devices
- 4 x Serial ATA 6Gb/s devices
Expansion
Slots
Storage
• 1 x D-sub (VGA) port
• 1 x HDMI port
• 1 x RJ45 LAN connector
• 4 x USB 2.0 ports
• 4 x USB 3.0 ports
• 1 x CLEAR_CMOS Button
• 1 x WIFI Connector
• 1 x Bluetooth Connector
• 2 x eSATA Connectors
• Audio jacks for line-in, line-out and Optical SPDIF Out
Rear Panel I/O
LAN • Realtek RTL 8111E Gigabit Lan
• Realtek ALC892 8-Ch High Definition audio CODEC
- Compliant with HD audio specification
Audio
• LGA1155 socket for latest 3
rd
Generation Intel Core
TM
i7/ i5/
i3/ Pentium/ Celeron Processors
• DMI 5.0GT/s
Note: Please go to ECS website for the latest Memory support list.
• 1 x 24-pin ATX Power Supply connector
• 1 x 8-pin 12V Power connector
• 1 x 4-pin CPU_FAN connector
• 1 x 3-pin SYS_FAN connector (Colay smart fan)
• 1 x 3-pin PWR_FAN connector
• 1 x USB 2.0 header supports additional two USB 2.0 ports
(F_USB1 supports EZ charger)
• 1 x USB 3.0 header supports additional two USB 3.0 ports
• 2 x Serial SATA 3Gb/s connectors
• 4 x Serial SATA 6Gb/s connectors
• 1 x COM header
• 1 x Case open header
• 1 x SPDIF out header
• 1 x Front Panel switch/LED header
Internal I/O
Connectors &
Headers
Note: Please go to ECS website for the latest CPU support list.
