![Asus a88xm-a/usb 3.1 [17/36] Accelerated processing unit apu](/views2/1213879/page17/bg11.png)
ASUS A88XM-A/USB 3.1
1-9
1.3 Accelerated Processing Unit (APU)
ThismotherboardcomeswithaFM2+socketdesignedforAMD
®
A-seriesandAthlon™Seriesprocessors.
UnplugallpowercablesbeforeinstallingtheAPU.
EnsurethatyouuseanAPUdesignedfortheFM2+socket.TheAPUtsinonlyone
correctorientation.DONOTforcetheAPUintothesockettopreventbendingthepinsand
damagingtheAPU!
Installing the APU
ApplytheThermalInterfaceMaterialtotheAPUheatsinkandAPUbeforeyouinstallthe
heatsink and fan if necessary.
1
43
2
