A88XM-A/USB 3.1 specifications summary
CPU
AMD
®
Socket FM2+ for A- series / Athlon™Series Processors
Supports CPU up to 4 cores
AMD
®
Turbo Core Technology 3.0 support*
* The AMD
®
Turbo Core Technology 3.0 support depends on the APU types.
** Refer to www.asus.com for AMD
®
APU support list.
Chipset
AMD
®
A88X FCH
Memory
4 x DDR3 DIMM, max. 64GB, DDR3 2400(O.C.)/2133/1866/1600/1333
MHz, non-ECC un-buffered memory Dual Channel memory architecture
* The Max. 64 GB memory capacity can be supported with DIMMs of 16GB (or
above). ASUS will update QVL once the DIMMs are available on the market.
** Refer to www.asus.com for the latest Memory QVL (Qualified Vendors List).
*** Due to OS limitation, when installing total memory of 4GB capacity or more,
Windows® 32-bit operation system may only recognize less than 3GB. Install
a 64-bit Windows® OS when you want to install 4GB or more memory on the
motherboard.
**** Hyper DIMM support is subject to the physical characteristics of individual
CPUs.
Expansion slots
1x PCI Express 3.0*/2.0 x16 slot
1 x PCI Express 2.0 x1 slot
1 x PCI slot
* Only FM2+ APU can support PCIe 3.0.
Storage
AMD
®
A88X FCH:
6 x Serial ATA 6Gb/s connectors(Grey) with RAID 0, RAID 1,RAID 5,RAID
10 and JBOD support
LAN
Realtek
®
8111H Gigabit LAN Controller
USB ASMedia USB 3.1 controllers - supports ASUS USB 3.1 Boost
-2 x USB 3.1 ports (2 ports at back panel,teal blue)
AMD
®
A88X FCH :
- 4 x USB 3.0 ports (2 ports at back panel, 2 ports at mid-board,blue)
- 6 x USB 2.0 ports (2 ports at back panel,4 ports at mid-board)
Package contents
Check your motherboard package for the following items.
Motherboard
ASUS A88XM-A/USB 3.1 motherboard
Cables 2 x Serial ATA 6.0 Gb/s cables
Accessories
1 x I/O Shield
Application DVD Support DVD
Documentation User Guide
If any of the above items is damaged or missing, contact your retailer.
