viii
A88XM-A/USB 3.1 specifications summary
Specications are subject to change without notice.
ASUS unique
features
ASUS Q-Design
- ASUS Q-Slot
UEFI BIOS EZ Mode
- Featuring a friendly graphical user interface
- ASUS CrashFree BIOS 3
- ASUS EZ Flash 2
Back Panel I/O
ports
1 x PS/2 keyboard port (purple)
1 x PS/2 mouse port (green)
1 x HDMI Port
1 x DVI Port
1 x D-Sub Output port
2 x USB 3.1 ports
2 x USB 3.0 ports
2 x USB 2.0/1.1 ports
1 x LAN (RJ-45) port
3 x Audio jacks support 8-channel audio output
Internal I/O
connectors
2 x USB 2.0/1.1 connector supports additional 4 USB 2.0/1.1 ports
1x USB 3.0/2.0 connector supports additional 2 USB 3.0/2.0 ports
6 x SATA 6.0Gb/s connectors (gray)
1 x System panel connector
1 x Internal Speaker connector
1 x CPU fan connector (4-pin)
1 x Chassis Fan connector
1 x S/PDIF Out connector
1 x High Denition front panel audio connector
1 x COM Header
1 x 24-pin EATX power connector
1 x 4-pin ATX 12V power connector
BIOS features
64 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI2.0, WfM2.0, SM BIOS 2.7,
ACPI 2.0a, Multi-language BIOS, ASUS EZ Flash 2, ASUS CrashFree BIOS
3, F12 PrintScreen Function, F3 Shortcut Function and ASUS DRAM SPD
(Serial Presence Detect) memory information
Support DVD Drivers
ASUS utilities
ASUS Update
Anti-virus software (OEM version)
Operating System
Support
Windows
®
10 (64-bit)
Windows
®
8.1 (64-bit)
Windows
®
7 (64-bit)
Windows
®
XP
Form factor
mATX form factor: 9.3 in x 8.2 in (23.6 cm x 20.8 cm)
