X99-E specifications summary
Audio
Realtek
®
ALC1150 8-channel high denition audio CODEC featuring Crystal
Sound 3
- Power pre-regulator reduces power input noise to ensure consistent
performance
- Top notch audio sensation delivers according to the audio conguration
- Audio shielding ensures precise analog/digital separation and greatly
reduced multi-lateral interference
- Unique de-pop circuit to reduce start-up popping noise to audio outputs
- Audio Amplier to enhance the highest quality sound for headphone and
speakers
- Separate layer for left and right track, ensuring both sound deliver equal
quality
- Premium Japan-made audio capacitors provides warm, natural, and
immersive sound with exceptional clarity and delity
- Absolute Pitch 192khz/24bit true BD lossless sound
- DTS
®
Connect
- Supports jack-detection, multi-streaming, front panel jack-retasking (MIC)
- Optical S/PDIF out port at back I/O
- BD audio layer content protection
- High quality 112dB SNR stereo playback output (Line-out@back) & 104dB
SNR recording input (Line-in) support
USB
Intel
®
X99 Chipset - supports ASUS USB 3.1 Boost
- 5 x USB 3.0/2.0 ports (4 ports at mid-board, 1 port at back panel)
- 8 x USB 2.0/1.1 ports (4 ports at mid-board, 4 ports at back panel)
ASMedia
®
USB 3.1 controller - supports ASUS USB 3.1 Boost
- 1 x USB 3.1/3.0/2.0 port at back panel (Type-C)
ASMedia
®
USB 3.0 - supports ASUS USB 3.1 Boost
- 3 x USB 3.0/2.0 ports (3 ports at back panel)
ASUS Exclusive
Features
<Performance>
5-Way Optimization
- Whole system optimization with a single click! Perfectly consolidates better
CPU performance, power saving, digital power control, system cooling and
app usages.
DIGI+ Power Control
- CPU Power: Digital 8-phase power design
- DRAM Power: Digital 4-phase power design
TPU
- Auto Tuning, TPU
EPU
Fan Xpert 4
Turbo Core App
(continued on the next page)
