xv
• If any of the above items is damaged or missing, contact your retailer.
• The illustrated items above are for reference only. Actual product specications may
vary with different models.
Package contents
Check your motherboard package for the following items:
ASUS X99-E motherboard
1 x Support DVD
4 x Serial ATA 6.0 Gb/s cables
1 x ASUS Q-Shield 1 x User Manual
User Manual
1 x Q-Connector
1 x ASUS 2-WAY/3-WAY SLI bridge
Motherboard
1 x M.2 screw package
