3
Catalyst 2960-S Switch Getting Started Guide
OL-19793-02
Catalyst 2960-S Switch Getting Started Guide
1 Catalyst 2960-S switch
1
1. Catalyst 2960S-48FPD-L switch shown for example. Your switch model might look different.
9 Four number-8 Phillips truss-head screws
(48-0656-01)
2 AC power cord 10 Four number-8 Phillips flat-head screws
(48-0655-01)
3 Four rubber mounting feet 11 Two number-4 pan-head screws (48-0482-01)
4 Documentation 12 One black Phillips machine screw (48-0654-01)
5 Two 19-inch mounting brackets 13 (Optional
3
) Console cable or USB cable
6 Connector
2
cover for redundant power
system
2. Only available on some models.
14 (Optional
3
) Cisco FlexStack module
7 Cable guide 15 (Optional
3
) Cisco FlexStack cable
8 Four number-12 Phillips pan-head screws
(48-0523-01)
16 (Optional
3
) Power cord retainer
3. Item is orderable.
Catalyst 2960-S Switch
Documentation
Catalyst 2960-S
Series
PoE+ 10G
11X
2X
1X
11X
14X
12X
13X
23X
2
4
X
25X
26X
3
7
X
39X
36X
38X
47X
48X
1
2
P
OWER
OVER
ETHERNET 740W
8
9
10
4
5
6
11
13
2
7
12
1
3
14 15 16
206224
