Catalyst 2960-S Switch Getting Started Guide

OL-19793-02

Catalyst 2960-S Switch Getting Started Guide

Step 7

Enter the required settings in the Express Setup window.

Note All entries must be in English letters and numbers.

Required Fields

Enter this information in the Network Settings fields:

• In the Management Interface (VLAN ID) field, the default is 1.

Note We recommend using the default VLAN value because during Express Setup, VLAN

1 is the only VLAN on the switch.

Enter a new VLAN ID only if you want to change the management interface through

which you manage the switch. The VLAN ID range is 1 to 1001.

• In the IP Address field, enter the IP address of the switch.

• In the Subnet Mask field, click the drop-down arrow, and select a subnet mask.

• In the Default Gateway field, enter the IP address for the default gateway (router).

• Enter your password in the Switch Password field. The password can be from 1 to 25

alphanumeric characters, can start with a number, is case sensitive, allows embedded

spaces, but does not allow spaces at the beginning or end. In the Confirm Switch

Password field, enter your password again.

Note You must change the password from the default password, cisco.

Optional Fields

You can enter other administrative settings in the Express Setup window. For example, the

optional administrative settings identify and synchronize the switch for enhanced

management. The switch clock is automatically synchronized with the network clock by using

NTP. You can manually set the system clock settings if the switch should have different time

settings.

Click Submit to save your changes and to complete the initial setup.

For more information about the Express Setup fields, see the online help for the Express Setup

window.

Step 8

After you click Submit, these events occur:

• The switch is configured and exits Express Setup mode.

• The browser displays a warning message and tries to connect with the earlier switch IP

address. Typically, connectivity between the PC and the switch is lost because the

configured switch IP address is in a different subnet from the IP address on the PC.
