Catalyst 2960-S Switch Getting Started Guide
8
Catalyst 2960-S Switch Getting Started Guide
OL-19793-02
Step 6
Enter the IP address 10.0.0.1 in a web browser
and press Enter.
When prompted, enter the default password,
cisco.
Note The switch ignores text in the
username field.
The Express Setup window appears.
Troubleshooting:
If the Express Setup window does not appear,
make sure that any pop-up blockers or proxy
settings on your browser are disabled and that
any wireless client is disabled on your PC or
laptop.
