How to use the touchscreen control panel

Use the following actions to use the printer touchscreen control panel.

Action Description Example

Touch

Touch an item on the screen to select that item

or open that menu. Also, when scrolling

through menus, briefly touch the screen to stop

the scrolling.

Touch Setup to open the Setup menu.

Swipe

Touch the screen and then move the finger

horizontally to scroll the screen sideways.

Swipe the Home screen to access the Setup

Scroll

Touch the screen, and then, without lifting the

finger, move the finger vertically to move the

screen.

Scroll through the Setup menu.

ENWW Printer views 9
