Update the firmware
HP offers periodic printer updates, new Web Services apps, and new features to existing Web Services apps.
Follow these steps to update the printer firmware for a single printer. When you update the firmware, Web
Service apps will update automatically.
There are two supported methods to perform a firmware update on this printer. Use only one of the following
methods to update the printer firmware.
Method one: Update the firmware using the control panel
Use these steps to load the firmware from the control panel (for network-connected printers only), and/or
set the printer to automatically load future firmware updates. For USB-connected printers, skip to method
two.
NOTE: The steps vary according to the type of control panel.
1 2
1 2-line control panel
2 Touchscreen control panel
2-line control panels:
1. Make sure the printer is connected to a wired (Ethernet) or wireless network with an active Internet
connection.
NOTE: The printer must be connected to the internet to update the firmware via a network
connection.
2. On the printer control panel, press the Setup button.
3. Open the Service menu, and then open the LaserJet Update menu.
NOTE: If the LaserJet Update option is not listed, use method two.
4. Select Check for Update to check for updates.
NOTE: The printer automatically checks for an update, and if a newer version is detected, the update
process automatically starts.
5. Set the printer to automatically update the firmware when updates become available.
On the printer control panel, press the Setup
button.
Open the Service menu, open the LaserJet Update menu, and then select the Manage Updates menu.
124 Chapter 8 Manage the printer ENWW
