19
The Various Features of the Cooker
The various functions featured with the oven are control-
led using the knobs and buttons on the control panel.
Control Knobs for the Gas Burners on the Hob
The position of the gas burner controlled by each one of the
knobs is shown by a symbol of a solid ring:
•. To light one of
the burners, hold a lighted match or lighter near the burner.
Press down and turn the corresponding knob in the counter-
clockwise direction to the maximum
setting. Each burner
can be operated at its maximum, minimum or intermediate
power. Shown on the knob are the different symbols for off
•
(the knob is on this setting when the symbol lines up with the
reference mark on the control panel), for maximum
and
minimum
.
To obtain these settings, turn the knob counter-clockwise
with respect to the off position. To turn off the burner, turn the
knob clockwise until it stops (corresponding again with the
•
symbol).
Electronic Lighting of the Hob Burners
Some models are equipped with instant electronic lighting of
the gas burners located on the hob, which can be identified
by the presence of an igniter device (see detail D). This de-
vice is activated by lighting pressing on the “L” button, identi-
fied by the
symbol. To turn on a burner, simply press the
“L” button and then press while, at the same time, pressing
in and turning the control knob for the burner in the anti-
clockwise direction until the burner lights. To light the burner
immediately, it is recommended that the button be
pressed first and then the knob turned.
Notice: The first time you use your appliance, we recom-
mend that you set the thermostat to the highest setting
and leave the oven on for about half an hour with nothing
in it, with the oven door shut. Then, open the oven door
and let the room air. The odour that is often detected dur-
ing this initial use is due to the evaporation of substances
used to protect the oven during storage and until it is in-
stalled.
Oven Control Knob (M)
This knob allows you to select the various features of the
oven and to set the most appropriate cooking tempera-
ture from among those indicated on the knob itself (be-
tween Min and Max).
To light the oven burner, hold a lighted match or lighter near
the "F" hole and, at the same time, press down and turn the
oven knob counter-clockwise to the Max setting.
F
Since the cooker is equipped with a safety device which
makes it necessary to keep the knob pressed in for about
6 seconds after the burner has been lighted to allow the
gas to pass through freely.
The cooking temperature is selected by matching the de-
sired temperature with the reference mark on the panel; the
complete range of temperatures is shown below.
Min • 160 • 180 • 220 Max
150 155 170 200 250
The temperature setting is then automatically reached and
kept constant by the thermostat (which is controlled by
the knob).
Important Notice: In the event the flame for the oven or the
grill accidentally goes out, turn the control knob for the burner
to the off position and do not relight the burner for at least
one minute.
Notice: Never use the bottom shelf and never place any-
thing on the bottom of the oven when it is in operation
because this could damage the enamel. Always place your
cookware (dishes, aluminium foil, etc. etc.) on the grid
provided with the appliance inserted especially along the
oven guides.
Oven Light Button (O)
This button is marked by the
3 symbol and switches on the
light inside the oven so that you can monitor the cooking
process without opening the door.
Timer
To use the timer, it must be wound using the "P" knob.
Turn the knob almost one full turn in the clockwise direction
. Then, turn the knob back , and set the time by
positioning the number (minutes) on the knob dial beneath
the mark on the control panel.
Caution
Keep children away from the oven door when in use be-
cause it becomes very hot.
Practical Advice on Using the Burners
To use the burners as efficiently as possible, some basic
guidelines should be followed:
• Use cookware that is the right size for each burner (see
table) in order to prevent the flame from spreading be-
yond the bottom of the cookware.
• Only use cookware with flat bottoms.
• As soon as the boiling point is reached, turn the knob to
the lowest setting.
• Always use lids with pots and pans.
Burner ø Cookware diameter (cm)
Fast (R) 24 - 26
Semi Fast (S) 16 - 20
Auxiliary (A) 10 - 14
N.B.: On models equipped with a reduction grid, the grid
should only be used with the auxiliary burner when
cookware with a diameter of less than 12 cm is used.
