Lenovo b51-30, 80lk00lfrk [13/52] Chapter 1 getting to know your computer

Chapter 1. Getting to know your computer

Ventilation slots

Dissipates internal heat.

Attention:

• Make sure that none of the ventilation slots are blocked or else overheating of the

computer may occur.

VGA port

Connects to external display devices.

RJ-45 port

Connects the computer to an Ethernet network.

Danger:

• To avoid the risk of electrical shock, do not connect a telephone cable to the Ethernet

port. You can only connect an Ethernet cable to this port.

HDMI port

Connects to devices with HDMI input such as a TV

or a display.

USB 3.0 ports

Connect to USB devices. For details, see

“Connecting USB devices” on page 8.

Note: The USB 3.0 connector is compatible with USB 1.1, 2.0, and 3.0.
