Chapter 1. Getting to know your computer

Bottom view - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -

Battery latch-manual

Keeps the battery pack secured in place.

Battery pack

Provide the power for the computer.

Battery latch-spring loaded

Keeps the battery pack secured in place.

Bottom slot cover

The hard disk drive, memory module, and

mini-PCI Express Card are placed

underneath.

31 2
