Chapter 1. Getting to know your computer
Right-side view - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
B41-35/B41-30/N41-35/N41-30:
B51-35/B51-30/N51-35/N51-30:
Combo audio jack
Connects to a headset.
Note:
• The combo audio jack does not support conventional microphones.
• The recording function might not be supported if third-party headphones or headsets
are connected due to different industry standards.
USB port
Connects to USB devices. For details, see “Connecting
USB devices” on page 8.
Novo button
When the computer is off, press this button to start
the Lenovo OneKey Recovery system, or to startup
normally, or the BIOS setup utility, or to enter the boot
menu.
1 2 3 4 5
1 2 3
5
4
a
b
c
