Lenovo b51-30, 80lk00lfrk [48/52] Replacing the keyboard

Appendix A. CRU instructions

Replacing the keyboard - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -

To replace the keyboard, do the following:

Remove the battery pack. For details, see “Replacing the battery pack” on

page 33.

Remove the screws .

Turn the computer over and open the display panel.

Note:

• Make sure the computer is turned off and all the cables disconnected from the computer

before you replace the keyboard.

• Make sure the computer display is closed to avoid being damaged.
