Accessories
For vertically mounted units
Design kit and extension hood
Mounting and installation
Type Description
PA3JK Vertical kit for PA3500(fig. 9)
PA4JK Vertical kit for PA4200 (fig. 9)
PA34EF10 External intake filter for PA3510/4210
PA34EF15 External intake filter for PA3515/4215
PA34EF20 External intake filter for PA3520/4220
PA34EF25 External intake filter for PA3525/4225
FHDN20
Flexible hoses DN20, inside thread, 90° bend, water temp.
up to 90° C
Type Description
PA3VDW15 Design kit for vertical mounting PA3515 Fig. 9
PA3VDW20 Design kit for vertical mounting PA3520 Fig. 9
PA3VDW25 Design kit for vertical mounting PA3525 Fig. 9
PA4VDW15 Design kit for vertical mounting PA4215 Fig. 9
PA4VDW20 Design kit for vertical mounting PA4220 Fig. 9
PA4VDW25 Design kit for vertical mounting PA4225 Fig. 9
PA3HE Extension hood for PA3500
PA4HE Extension hood for PA4200
See manual for FHDN20.
See manual for PA34EF.
See manual for PA3HE/PA4HE.
