PA3500/4200
21
Output charts water PA3500
PA3500 WL
Standard coil Incoming / outgoing water temperature 80/60 °C
Incoming air temp. = +15 °C Incoming air temp. = +20 °C
Type Fan
position
Airflow
[m
3
/h]
Output
[kW]
Outgoing
air temp.
[°C]
Water
flow
[l/s]
Pressure
drop
[kPa]
Output
[kW]
Outgoing
air temp.
[°C]
Water
flow
[l/s]
Pressure
drop
[kPa]
PA3510WL max 1800 21,7 50 0,26 21,4 19,4 52 0,24 1 7, 5
min 860 12,9 59 0,16 8,3 11,5 60 0,14 6,8
PA3515WL max 2600 33,1 52 0,40 32,1 29,7 54 0,36 26,3
min 1240 19,4 61 0,24 12,1 1 7, 4 68 0,21 10,0
PA3520WL max 3200 42,0 53 0,51 19,9 37,7 55 0,46 16,4
min 1530 24,2 62 0,30 7, 5 21,9 62 0,27 6,2
PA3525WL max 4600 59,1 52 0,72 44,2 53,1 54 0,65 36,3
min 2200 34,6 61 0,42 16,7 31,1 62 0,38 13,8
PA3500 WL
Standard coil Incoming / outgoing water temperature 60/50 °C
Incoming air temp. = +15 °C Incoming air temp. = +20 °C
Type Fan
position
Airflow
[m
3
/h]
Output
[kW]
Outgoing
air temp.
[°C]
Water
flow
[l/s]
Pressure
drop
[kPa]
Output
[kW]
Outgoing
air temp.
[°C]
Water
flow
[l/s]
Pressure
drop
[kPa]
PA3510WL max 1800 15,9 41 0,39 44,3 13,7 43 0,33 33,9
min 860 9,3 47 0,23 1 7, 0 8,1 48 0,20 13,0
PA3515WL max 2600 24,2 42 0,59 66,1 20,9 44 0,51 50,6
min 1240 14,0 48 0,34 24,6 12,1 49 0,29 18,9
PA3520WL max 3200 30,6 43 0,74 41,1 26,5 45 0,64 31,4
min 1530 1 7, 7 49 0,43 15,1 15,3 50 0,37 11,6
PA3525WL max 4600 43,0 42 1,04 90,8 37,2 44 0,90 69,6
min 2200 25,0 48 0,61 33,8 21,6 49 0,52 26,0
PA3500 WL
Standard coil Incoming / outgoing water temperature 60/40 °C
Incoming air temp. = +15 °C Incoming air temp. = +20 °C
Type Fan
position
Airflow
[m
3
/h]
Output
[kW]
Outgoing
air temp.
[°C]
Water
flow
[l/s]
Pressure
drop
[kPa]
Output
[kW]
Outgoing
air temp.
[°C]
Water
flow
[l/s]
Pressure
drop
[kPa]
PA3510WL max 1800 13,0 36 0,16 9,0 10,8 38 0,13 6,4
min 860 7, 8 41 0,09 3,6 6,5 42 0,08 2,6
PA3515WL max 2600 20,1 38 0,24 13,7 16,8 39 0,20 9,9
min 1240 11,9 43 0,14 5,4 9,9 44 0,12 3,9
PA3520WL max 3200 25,5 38 0,31 8,5 21,2 40 0,26 6,2
min 1530 15,0 44 0,18 3,3 12,5 44 0,15 2,4
PA3525WL max 4600 36,2 38 0,44 19,2 30,2 40 0,37 13,9
min 2200 21,4 43 0,26 7, 5 1 7, 9 44 0,22 5,5
PA3500 WL
Standard coil Incoming / outgoing water temperature 60/30 °C
Incoming air temp. = +15 °C Incoming air temp. = +20 °C
Type Fan
position
Airflow
[m
3
/h]
Output
[kW]
Outgoing
air temp.
[°C]
Water
flow
[l/s]
Pressure
drop
[kPa]
Output
[kW]
Outgoing
air temp.
[°C]
Water
flow
[l/s]
Pressure
drop
[kPa]
PA3510WL max 1800 9,4 30 0,08 2,5 6,9 31 0,06 1,5
min 860 5,6 34 0,05 1,0 3,9 34 0,03 0,6
PA3515WL max 2600 15,1 32 0,12 4,1 11,3 33 0,09 2,5
min 1240 9,0 36 0,07 1,7 6,7 36 0,05 1,0
PA3520WL max 3200 18,9 32 0,15 2,5 14,0 33 0,11 1,5
min 1530 11,2 36 0,09 1,0 8,0 35 0,06 0,6
PA3525WL max 4600 27,7 33 0,22 5,9 21,0 34 0,17 3,6
min 2200 16,6 37 0,13 2,4 12,6 37 0,10 1,5
