PA3500/4200
26
Technical specifications | Thermozone PA4200 A without heat 1
Type Output
[kW]
Airflow*
1
[m
3
/h]
Sound
level*
2
[dB(A)]
Output
motor
[W]
Voltage
motor
[V]
Amperage
motor
[A]
Length
[mm]
Weight
[kg]
PA4210A 0 1280/2700 46/63,5 830 230V~ 3,6 1039 43
PA4215A 0 1760/3700 46/64 115 0 230V~ 5,0 1549 56
PA4220A 0 2520/5300 47/64,5 1610 230V~ 7, 0 2039 75
PA4225A 0 3020/6350 48,5/67 1990 230V~ 8,6 2549 91
Technical specifications | Thermozone PA4200 E with electrical heat 3
Type Output
steps
[kW]
Airflow*
1
[m
3
/h]
∆t
*4
[°C]
Sound
level*
2
[dB(A)]
Output
motor
[W]
Voltage
motor
[V]
Amperage
motor
[A]
Voltage [V]
Amperage [A]
heat
Length
[mm]
Weight
[kg]
PA4210E12 3,9/7,8/12,0 1280/2700 37/14 46/63,5 830 230V~ 3,6 400V3~/17,3 1039 50
PA4215E18 6,0/12,0/18,0 1760/3700 40/15 46/64 115 0 230V~ 5,0 400V3~/26,0 1549 71
PA4220E24 7,8/15,6/24,0 2520/5300 37/14 47/64,5 1610 230V~ 7, 0 400V3~/34,6 2039 94
PA4225E30 9,9/19,8/30,0 3020/6350 38/15 48,5/67 1990 230V~ 8,6 400V3~/43,0 2549 113
Technical specifications | Thermozone PA4200 WL with water heat, coil for low temperature water < 80/60 °C 2
Type Output*
3
[kW]
Airflow*
1
[m
3
/h]
∆t
*3,4
[°C]
Water-
volume
[l]
Sound
level*
2
[dB(A)]
Output
motor
[W]
Voltage
motor
[V]
Amperage
motor
[A]
Length
[mm]
Weight
[kg]
PA4210WL 31 1280/2700 42/33 1,87 46/63,5 830 230V~ 3,6 1039 50
PA4215WL 45 1760/3700 44/36 2,96 46/64 115 0 230V~ 5,0 1549 67
PA4220WL 64 2520/5300 44/35 4,14 47/64,5 1610 230V~ 7, 0 2039 90
PA4225WL 79 3020/6350 45/36 5,21 48,5/67 1990 230V~ 8,6 2549 109
Technical specifications | Thermozone PA4200 WH with water heat, coil for high temperature water ≥ 80/60 °C 2
Type Output*
3
[kW]
Airflow*
1
[m
3
/h]
∆t
*3,4
[°C]
Water-
volume
[l]
Sound
level*
2
[dB(A)]
Output
motor
[W]
Voltage
motor
[V]
Amperage
motor
[A]
Length
[mm]
Weight
[kg]
PA4210WH 15 1280/2700 22/16 1,27 46/63,5 830 230V~ 3,6 1039 49
PA4215WH 22 1760/3700 23/17 2,03 46/64 115 0 230V~ 5,0 1549 65
PA4220WH 32 2520/5300 23/17 2,72 47/64,5 1610 230V~ 7, 0 2039 87
PA4225WH 38 3020/6350 23/18 3,80 48,5/67 1990 230V~ 8,6 2549 105
Protection class for units with electrical heating: IP20.
Protection class for units without heating and units with water heating: IP21.
CE compliant.
*
1
) Lowest/highest airflow of totally 5 fan steps.
*
2
) Conditions: Distance to the unit 5 metres. Directional factor: 2. Equivalent absorption area: 200 m². At
lowest/highest airflow.
*
3
) Applicable at water temperature 80/60 °C, air temperature, in +15 °C.
*
4
) ∆t = temperature rise of passing air at maximum heat output and lowest/highest airflow.
