Gigabyte GA-Z97M-D3H [4/40] Ga z97m d3h ga h97m d3h
![Gigabyte GA-Z97M-D3H [4/40] Ga z97m d3h ga h97m d3h](/views2/1233003/page4/bg4.png)
- 4 -
The box contents above are for reference only and the actual items shall depend on the product package you obtain.
The box contents are subject to change without notice.
Box Contents
5 GA-Z97M-D3H or GA-H97M-D3H motherboard
5 Motherboard driver disk 5 Two SATA cables
5 User's Manual 5 I/O Shield
GA-Z97M-D3H/GA-H97M-D3H Motherboard Layout
F_USB30
KB_MS_USB
CPU_FAN
LGA1150
ATX
AUDIO
DDR3_4
DDR3_2
DDR3_3
DDR3_1
BAT
ATX_12V_2X4
Intel
®
Z97j
Intel
®
H97k
CODEC
CLR_CMOS
M_BIOS
B_BIOS
VGA
DVI
USB30
LAN
PCIEX16
PCI1
PCI2
PCIEX4
SYS_FAN2
SYS_FAN1
GA-Z97M-D3H/GA-H97M-D3H
R_USB30
HDMI
F_PANEL
SYS_FAN3F_USB3 F_USB1COM
F_USB2
F_AUDIO
SPDIF_O
LPT TPM
SATA3
1 3 5
0 2 4
Realtek
®
GbE LAN
PCIe to PCI
Bridge
iTE
®
Super I/O
j Only for GA-Z97M-D3H.
k Only for GA-H97M-D3H.
