Asus PRIME X370-A Руководство пользователя онлайн
Содержание
- E12715 first edition april 2017 2
- Appendix 3
- Chapter 1 product introduction 3
- Chapter 2 bios information 3
- Contents 3
- About this guide 4
- Electrical safety 4
- How this guide is organized 4
- Operation safety 4
- Safety information 4
- Conventions used in this guide 5
- Typography 5
- Where to find more information 5
- Check your motherboard package for the following items 6
- Package contents 6
- Prime x370 a specifications summary 6
- Dependable stability 7
- Easy pc diy 7
- Prime x370 a specifications summary 7
- Quiet thermal design 7
- Superb performance 7
- Prime x370 a specifications summary 8
- Asus prime x370 a 9
- Before you proceed 9
- Chapter 1 product introduction 9
- Motherboard overview 9
- Product introduction 9
- Take note of the following precautions before you install motherboard components or change any motherboard settings 9
- Atx power connectors 24 pin eatxpwr 8 pin eatx12v 10
- Chapter 1 product introduction 10
- Connectthefancablestothefanconnectorsonthemotherboard ensuringthatthe black wire of each cable matches the ground pin of the connector 10
- Cpu and chassis fan connectors 4 pin cpu_fan 4 pin cha_fan1 2 10
- Layout contents 10
- Theseconnectorsareforatxpowersupplyplugs thepowersupplyplugsare designedtofittheseconnectorsinonlyoneorientation findtheproperorientationand pushdownfirmlyuntiltheconnectorscompletelyfit 10
- Amd am4 cpu socket 11
- Asus prime x370 a 11
- Fan rgb header 4 pin fan_rgb_header 11
- M socket 3 11
- M socket3 11
- These sockets allow you to install m ngff ssdmodules 11
- Thisheaderisforrgbledstripsofacpu fan 11
- Thismotherboardcomeswithanamdam4socketdesignedforamdryzen 7th generationa series athlon processors 11
- Asus prime x370 a 15
- For7thgenerationa series athlon processors 15
- Forryzen processors 15
- Irq assignments for this motherboard 15
- Rear panel connectors 16
- Asus prime x370 a 17
- Audio2 4 5 or7 channelconfiguration 17
- Dvi d port thisportisforanydvi dcompatibledevice 17
- Hdmi port thisportisforahigh definitionmultimediainterface hdmi connector andishdcpcompliantallowingplaybackofhddvd blu ray andotherprotected content 17
- Usb 2 ports these4 pinuniversalserialbus usb portsareforusb2 1 devices 17
- Central processing unit cpu 18
- Chapter 1 product introduction 18
- Installing the cpu 18
- Themotherboardcomeswithanamdam4socketdesignedfor amdryzen 7thgenerationa series athlon processors 18
- Chapter 1 product introduction 20
- Installing a dimm 20
- Overview 20
- Recommendedmemoryconfigurations 20
- System memory 20
- Thismotherboardcomeswithfourdoubledatarate4 ddr4 dualinlinememorymodule dimm sockets thefigureillustratesthelocationoftheddr4dimmsockets 20
- Installing an operating system 21
- Software support 21
- Support dvd information 21
- To run the support dvd 21
- Bios information 22
- Chapter 2 bios information 22
- Ez update 22
- Managing and updating your bios 22
- Asus ez flash 3 23
- Asus bios updater 24
- Asus crashfree bios 3 utility 24
- Before updating bios 24
- Recovering the bios 24
- Booting the system in dos environment 25
- Updating the bios file 25
- Bios menu screen 26
- Bios setup program 26
- Entering bios setup after post 26
- Entering bios setup at startup 26
- 6 chapter 2 bios information 27
- Ez mode 27
- The boot device options vary depending on the devices you installed to the system 27
- The default screen for entering the bios setup program can be changed refer to the setup mode item in section 2 boot menu for details 27
- Advanced mode 28
- Asus prime x370 a 2 7 28
- The advanced mode provides advanced options for experienced end users to configure the bios settings the figure below shows an example of the advanced mode refer to the following sections for the detailed configurations 28
- Hot keys 29
- Language 29
- Menu bar 29
- Menu items 29
- Myfavorites f3 29
- Q fan control f6 29
- Scroll bar 29
- Submenu items 29
- Configuration fields 30
- General help 30
- Last modified button 30
- Search on faq 30
- 10 chapter 2 bios information 31
- Qfan control 31
- The qfan control allows you to set a fan profile or manually configure the operating speed of your cpu and chassis fans 31
- Configuring fans manually 32
- Adding items to my favorites 33
- My favorites 33
- Language english 34
- Main menu 34
- Security 34
- 한국어 34
- Administrator password 35
- User password 35
- Ai overclock tuner auto 36
- Ai tweaker menu 36
- Apu frequency xxx 36
- Apu multiplier auto 37
- Custom cpu core ratio auto 37
- Epu power saving mode disabled 37
- Memory frequency auto 37
- Digi vrm 38
- Dram timing control 38
- Oc tuner keep current settings 38
- Target tdp auto 38
- Tdp configuration 38
- Vddcr cpu load line calibration auto 38
- Vddcr soc load line calibration auto 38
- Vddcr cpu offset mode sign 39
- Vddcr cpu power phase control optimized 39
- Vddcr cpu switching frequency auto 39
- Vddcr cpu voltage auto 39
- Vddcr soc offset mode sign 39
- Vddcr soc voltage auto 39
- 1 5v sb voltage auto 40
- 2 v sb voltage auto 40
- Cpu 1 0v voltage auto 40
- Dram voltage auto 40
- Vddp voltage auto 40
- Vpp_mem voltage auto 40
- Vttddr voltage auto 40
- Advanced menu 41
- Amd ftpm switch disabled 41
- Cpu configuration 41
- Nx mode enabled 41
- Pss support enabled 41
- Svm mode disabled 41
- Bank interleaving enabled 42
- C6 mode enabled 42
- Channel interleaving enabled 42
- Core leveling mode automatic mode 42
- Cpb mode enabled 42
- Hyper kit mode disabled 42
- Igfx multi monitor disabled 42
- Iommu disabled 42
- Nb configuration 42
- Primary video device pcie pci video 42
- Sata configuration 42
- Uma frame buffer size auto 42
- Fan rgb enabled 43
- Hd audio controller enabled 43
- Hot plug disabled sata6g_1 gray sata6g_6 gray 43
- Led lighting breathing mode 43
- Onboard devices configuration 43
- Sata mode ahci 43
- Sata port enable enabled 43
- Smart self test on 43
- Charging usb devices in power state s5 enabled 44
- Erp ready disabled 44
- Power on by pci e pci disabled 44
- Power on by ring disabled 44
- Power on by rtc disabled 44
- Realtek lan controller on 44
- Realtek pxe oprom off 44
- Restore ac power loss power off 44
- Serial port configuration 44
- Ehci hand off enabled 45
- Hdd ssd smart information 45
- Ipv4 ipv6 pxe support enabled 45
- Legacy usb support enabled 45
- Network stack configuration 45
- Network stack disabled 45
- Usb configuration 45
- Usb device enable enabled 45
- Usb single port control 45
- Amd cbs 46
- Cpu fan chassis fan 1 2 speed xxxx rpm ignore n a 46
- Cpu mb temperature xxx º c xxx º f ignore 46
- Monitor menu 46
- Vddcr cpu voltage 3 v voltage 5v voltage 12v voltage 46
- Cpu fan profile standard 47
- Cpu fan speed lower limit 200 rpm 47
- Cpu q fan control pwm mode 47
- Q fan configuration 47
- Q fan tuning 47
- Chassis fan 1 2 profile standard 48
- Chassis fan 1 2 q fan control dc mode 48
- Chassis fan 1 2 q fan source cpu 48
- Chassis fan 1 2 speed low limit 200 rpm 48
- Chassis fan s configuration 48
- Boot menu 49
- Fast boot enabled 49
- Next boot after ac power loss normal boot 49
- Boot configuration 50
- Boot logo display auto 50
- Bootup numlock state enabled 50
- Csm compatibility support module 50
- Interrupt 19 capture disabled 50
- Option rom messages force bios 50
- Setup mode ez mode 50
- Wait for f1 if error enabled 50
- Boot device control uefi and legacy oprom 51
- Boot from network devices legacy only 51
- Boot from pci e pci expansion devices legacy only 51
- Boot from storage devices legacy only 51
- Key management 51
- Launch csm enabled 51
- Os type other os 51
- Secure boot 51
- Boot option priorities 53
- Boot override 53
- Asus ez flash 3 utility 54
- Asus overclocking profile 54
- Load from profile 54
- Load save profile from to usb drive 54
- Profile name 54
- Save to profile 54
- Setup animator disabled 54
- Tool menu 54
- Asus spd information 55
- Dimm slot number dimm_a1 55
- Discard changes and exit 55
- Exit menu 55
- Launch efi shell from usb drives 55
- Load optimized defaults 55
- Save changes reset 55
- Appendix 56
- Déclaration de conformité d industrie canada 56
- Federal communications commission statement 56
- Ic canadian compliance statement 56
- Notices 56
- Asus recycling takeback services 57
- Canadian department of communications statement 57
- Class b ite 57
- Kc korea warning statement 57
- Regional notice for california 57
- Vcci japan compliance statement 57
- Asus prime x370 a 58
- Copyright 2017 google inc all rights reserved 58
- Google license terms 58
- Http www apache org licenses license 2 58
- Licensedundertheapachelicense version2 the license youmaynotusethisfile except in compliance with the license you may obtain a copy of the license at 58
- Seethelicenseforthespecificlanguagegoverningpermissionsandlimitationsunderthe license 58
- Unless required by applicable law or agreed to in writing software distributed under the license is distributed on an as is basis without warranties or conditions of any kind either express or implied 58
- Asus computer gmbh germany and austria 59
- Asus computer international america 59
- Asus contact information 59
- Asustek computer inc 59
- Technical support 59
- Asus computer international 60
- Ca 94539 60
- Declaration of conformity 60
