vii
PRIME Z270-P specifications summary
(continued on the next page)
Specifications
Storage
Intel
®
Z270 Express Chipset with RAID 0, 1, 5, 10 and Intel Rapid Storage Technology
15 support
- 2 x M.2 Socket 3 with M Key, type 2242/2260/2280 storage devices support
(SATA mode & x4 PCIE mode)*
- 4 x SATA 6.0 Gb/s ports (gray)
- Ready for Intel
®
Optane Memory**
- Supports Intel
®
Smart Response Technology***
* When a device in SATA mode is installed on the M.2_1 socket, SATA_1 port cannot be
used.
** Intel
®
Optane Technology is only supported when using the 7th Generation Intel
®
Processors. Before using Intel
®
Optane memory modules, ensure that you have updated
your motherboard drivers and BIOS to the latest version from ASUS support website.
*** These functions work depending on the type of CPU installed.
LAN
Realtek
®
RTL8111H Gigabit LAN controller supports ASUS LANGuard
Audio
Realtek
®
ALC887 8-channel High Denition Audio CODEC
- LED-illuminated design: Brighten up your build with the gorgeous illuminated
audio trace path
- Audio Shielding: Ensures precision analog/digital separation and greatly reduces
multi-lateral interference
- Dedicated audio PCB layers: Separate layers for left and right channels to guard
the quality of the sensitive audio signals
- Premium Japanese audio capacitors: Provide warm, natural and immersive
sound with exceptional clarity and delity
- Supports jack-detection, and front panel jack-retasking
USB
Intel
®
Z270 Express Chipset
- 8 x USB 3.0/2.0 ports (4 ports @mid-board; 4 ports @back panel, blue, Type A)
- 6 x USB 2.0/1.1 ports (4 ports @mid-board; 2 ports @back panel)
ASUS
unique
features
ASUS 5X PROTECTION III
- ASUS SafeSlot Core - Fortied PCIe Slot prevents damage
- ASUS LANGuard - Protects against LAN surges, lightning strikes and static-
electricity discharges
- ASUS Overvoltage Protection - World-class circuit-protecting power design
- ASUS Stainless Steel Back I/O - 3X corrosion-resistance for greater durability
- ASUS DIGI+ VRM - 7 phase digital power design
Superb Performance
M.2 onboard
- The latest transfer technologies with up to 32Gb/s data transfer speeds
ASUS Fan Xpert 2+
- Ultimate cooling and quietness
ASUS EPU
- EPU
UEFI BIOS
- Most advanced options with fast response time
