PRIME H270-PRO specications summary
(continued on the next page)
Package contents
Check your motherboard package for the following items.
Motherboard
ASUS PRIME H270-PRO motherboard
Cables
2 x Serial ATA 6.0 Gb/s cables
Accessories
1 x ASUS Q-Shield
2 x M.2 screws
Application DVD Support DVD
Documentation User Guide
If any of the above items is damaged or missing, contact your retailer.
Specications
CPU
LGA1151 socket for Intel
®
7th/6th Generation Core™ i7 / i5 / i3, Pentium
®
, and
Celeron
®
processors
Supports Intel
®
14nm CPU
Supports Intel
®
Turbo Boost Technology 2.0*
* The Intel
®
Turbo Boost Technology 2.0 support depends on the CPU types.
** Refer to www.asus.com for Intel
®
CPU support list.
Chipset
Intel
®
H270 Chipset
Memory
4 x DIMM, maximum 64 GB, DDR4 2400*/ 2133**MHz, non-ECC, un-buffered
memory
Dual-channel memory architecture
Supports Intel
®
Extreme Memory Prole (XMP)
* Due to Intel
®
chipset limitation, DDR4 2400MHz memory frequency is only supported
by 7th Generation Intel
®
processors. Higher memory modules will run at the maximum
transfer rate of DDR4 2400MHz.
** Due to Intel
®
chipset limitation, DDR4 2133MHz and higher memory modules on 6th
Generation Intel
®
processors will run at the maximum transfer rate of DDR4 2133MHz.
*** Refer to www.asus.com for the latest Memory QVL (Qualied Vendors List).
Expansion
slots
1 x PCI Express 3.0/2.0 x16 slot (at x16 mode)
1 x PCI Express 3.0/2.0 x16 slot (max. at x4 mode, compatible with PCIe x1, x2
and x4 devices)
2 x PCI Express 3.0/2.0 x1 slots
2 x PCI slots
Multi-GPU
support
Supports AMD
®
CrossFireX™ Technology
Graphics
Integrated graphics processor - Intel
®
HD Graphics support
Multi-VGA output support: DP, HDMI, DVI-D ports
- Supports DisplayPort 1.2 with maximum resolution of 4096 x 2304 @ 60Hz
- Supports HDMI 1.4b with maximum resolution of 4096 x 2160 @ 24Hz / 2560
x 1600 @ 60Hz
- Supports DVI-D with maximum resolution of 1920 x 1200 @ 60Hz
Supports Intel
®
InTru
TM
3D, Quick Sync Video, Intel
®
Clear Video HD Technology,
and Intel
®
Insider
TM
Maximum shared memory of 1024 MB (for iGPU exclusively)
Supports up to three displays simultaneously
