ASUS ROG & ROG STRIX Z200 Series Feature Manual
Synchronized control
Click the Synchronized tab for synchronized control of AURA effects.
Aura
Aura allows you to adjust the onboard RGB LEDs’ color and also select different light effects.
You can also correct or adjust the RGB LED color by calibrating the LED strip.
A header calibration pop-up window will appear when you select a header for the rst time.
Ensure to update to the latest motherboard BIOS before installing the software.
Click to associate
or disassociate
the device from
the synchronized
control group
Adjust AURA
lighting options
Select the desired AURA
lighting effect when the
system has been turned on
Click to enable the
default settings
Click to apply
the changes
Click to undo
the changes
