xi
(continued on the next page)
USB
Intel
®
Z270 Chipset:
- 6 x USB 3.0 ports ( 4 ports at back panel [blue], 2 ports at mid-
board [grey])
- 6 x USB 2.0 ports ( 4 ports at back panel [black], 2 ports at mid-
board [black])*
ASMedia
®
USB 3.1 controller:
- 1 x USB 3.1 front panel connector
- 2 x USB 3.1 ports (1 Type-A [red] and 1 Type-C [black] at back
panel)
* 2 x USB 2.0 ports at mid-board share with ROG extension (ROG_EXT)
port.
ROG Exclusive Features
Extreme Engine Digi+
- MicroFine Alloy Choke
- NexFET MOSFETs
- 10K Black Metallic Capacitors
ROG Armor
ROG Aura
- Aura effects
- 2 x Aura RGB strip headers
Start Button
Reset Button
Safe Boot Button
ReTry Button
BIOS Flashback Button
Clear CMOS Button
MemOK! Button
LN2 Mode
ROG RAMDisk
ROG CloneDrive
ROG RAMCache II
KeyBot II
- X.M.P.
- Clr CMOS
- Power On
UEFI BIOS features :
- Extreme Tweaker
- Tweakers’ Paradise
- ROG SSD Secure Erase
- GPU Post
- O.C. Prole
- Graphics Card Information Preview
MAXIMUS IX CODE specifications summary
