1. Technical Data
Use for the intended purpose
WARNING
REMS electric die stocks for cutting pipe thread for right and left hand thread (REMS Mini-Amigo, REMS Amigo E).
REMS electric die stocks for cutting pipe thread and bolt thread for right and left hand thread (REMS Amigo, REMS Amigo 2, REMS Amigo 2 Compact).
All other uses are not for the intended purpose and are prohibited.
1.1. Article numbers REMS REMS REMS REMS REMS Amigo 2
Mini-Amigo Amigo E Amigo Amigo 2 Compact
Drive unit 530001 530003 530000 540000 540001
Guiding support 533100 533000 533000 543000 543010
REMS Dual purpose holder 543100 543100 543100 543100
      
pipe threads R ¼” 521010 521010 521010 521010 521010
      
ISO 7-1 R ½” 521030 521030 521030 521030 521030
(DIN 2999, BSPT) R ¾” 521040 521040 521040 521040 521040
R 1” 521050 521050 521050 521050
R 1¼” 521060 521060 521060
R 1½” 521070 521070
R 2” 521080 521080
1.2. Capacity
Thread diameters
     
     
Types of threads
External threads
right- and left-hand R (ISO 7-1, DIN 2999, BSPT) NPT
  
(with button die) BSPP) NPSM
Threads for electric conduit M×1.5 (DIN EN 60423, IEC)
Pipe threads parallel
  
Bolt threads
  
Thread lengths
Pipe threads tapered standard length
Pipe threads parallel,
conduit, bolt 50 mm (with reclamping unlimited)
Nipples and double-nipples with
the REMS Nippelspanner
     
1.3. Revolutions of die head

     
1.4. Electrical data
230 V, 50/60 Hz
Power input 500 W 950 W 1200 W 1700 W 1200 W
Rated current input 2.3 A 6 A 6 A 8.3 A 6 A
Fuse protection 10 A (B) 10 A (B) 10 A (B) 16 A (B) 10 A (B)
Intermittent service 2/10 min 2/10 min 2/10 min 2/10 min 2/10 min
110 V, 50/60 Hz
Power input 500 W 950 W 1200 W 1700 W 1200 W
Rated current input 4.6 A 12 A 12 A 16.6 A 12 A
Fuse protection 20 A 20 A 20 A 30 A 20 A
Intermittent service 2/10 min 2/10 min 2/10 min 2/10 min 2/10 min
When cutting taper threads the rated current may increase for a short moment by about 50 %, without interference of the function ot the unit.
The drive units REMS Amigo and REMS Amigo 2 Compact are equipped with an overload protection which disconnects the motor when overloaded. In this case,
press green button (10) on the motor handle. See also section 5. Troubles.
1.5. Dimensions
L x W x H (mm) 270 x 85 x 160 430 x 80 x 195 440 x 85 x 195 565 x 112 x 237 500 x 90 x 215
10.6” x 3.3” x 6.3” 16.92” x 3.15” x 7.7” 17.3” x 3.3” x 7.7” 22.2” x 4.4” x 9.3” 19.7” x 3.5” x 8.5”
1.6. Weights
Drive unit 2.7 kg (6.0 lb) 3.4 kg (7.5 lb) 3.5 kg (7.7 lb) 6.5 kg (14.3 lb) 4.9 kg (10.8 lb)
Support 0.6 kg (1.3 lb) 1.3 kg (2.9 lb) 1,3 kg (2.9 lb) 2.9 kg (6.4 lb) 2,6 kg (5.7 lb)
Die heads 0.6 ... 0.7 kg 0.6 ... 0.8 kg 0.6 ... 0.8 kg 0.6 ... 1.3 kg 0.6 ... 1.3 kg
1.3 ... 1.6 lb 1.3 ... 1.8 lb 1.3 ... 1.8 lb 1.3 ... 2.9 lb 1.3 ... 2.9 lb
1.7. Noise information
Emission at workplace 84 dB (A) 83 dB (A) 83 dB (A) 82 dB (A) 83 dB (A)
1.8. Vibrations
Weighted effective value of
acceleration 3.5 m/s² 2.5 m/s² 2.5 m/s² 2.5 m/s² 2.5 m/s²
The indicated weighted effective value of acceleration has been measured against standard test procedures and can be used by way of comparison with another
device. The indicated weighted effective value of acceleration can also be used as a preliminary evaluation of the exposure.
Attention: The indicated weighted effective value of acceleration can differ during operation from the indicated value, dependent on the manner in which the device
is used. Dependent upon the actual conditions of use (periodic duty) it may be necessary to establish safety precautions for the protection of the operator.
