Example of stabilizer power calculation*

The refrigerator (rated power 300 W), TV (400 W), air-conditioner

(1000 W), radio (100 W), electric lamp (200 W) works in stationary mode.

The total power: 300+400+1000+100+200 = 2000 W

During simultaneous activation of all these electrical appliances can

be connected the iron(1000 W), vacuum-cleaner(800 W) and electric kettle

(1000 W). In this case the total load can be increased by 800-2000 W.

The max total power is: 2000 + 2800 = 4800 W

So stabilizer power =4880 + 25 % = 6000 W

So, during simultaneous activation of all these electrical appliances, we

need stabilizer with total power not less than 6 kW.

* power calculation is made for stabilizer with input voltage from 190 V.

If the voltage less than 190 V, please look fig.1.

5. Operating conditions

• The environment is not explosive, without current-conducting dust,

aggressive gases, etc.

• Min distance from the case to the walls = 30cm

• No direct sunbeams

• The stabilizer must be grounded

• The stabilizer SDF, SDV must be operated on the horizontal solid surface

• The stabilizer SDW must be effectively connected on the vertical surface

ATTENTION! During operation of stabilizer it is necessary to check the total

power of all consumers and max stabilizer power with input voltage. Remember

please, the power consumption increases in 3-5 times during starting (for

example electric motor)
