Telwin t-charge 18 boost [4/48] Charge



        



 



 





          



 

















 



 





    

    

    







   



 













          







        



 





 







 



        

       



 





        



 

 









       



 



 

       

       







        



      

       

    



       











    

   









      

      



 



    

    



       



    

     



 











       



        

















       







Содержание

Похожие устройства

battery Short circuit charging clamps set in contact with one another Polarity reversal of the battery The appliance is protected against overload short circuits and reverse polarity by means of internal electronic safeguards exclusively to a power source with the neutral lead connected to earth Check that the net voltage is the same as the voltage of the equipment Check that the power supply is protected by systems as fuses or automatic switches sufficient to support the maximum absorption of welding If you put an extension to the primary cable the diameter must be the same never inferior The connection to the power has to be made using the cable 7 USEFUL ADVICE Clean the positive and negative terminals of possible oxidation so as to ensure good contact with the clamps If the battery charger is used with a battery which is always connected to a vehicle check the instruction and or maintenance manual of the vehicle under the paragraph ELECTRICSYSTEM or MAINTENANCE Before charging it is advisable to disconnect the positive cable which is part of the electrical system of the vehicle 5 OPERATION BEFORE CHARGING NB Before charging check that the capacity of the battery Ah which is to be charged is not inferior to that reported on the data table C min Follow the instructions taking great care to respect the order given below Remove the caps of the battery charger if foreseen so as to let the gas produced go out Check that the level of the electrolyte covers the plates of the battery If these were not covered add distilled water and cover them up to 5 10 mm A WARNING USE THE MAXIMUM CAUTION AX DURING THIS OPERATION AS THE ELECTROLYTE IS A HIGHLY CORROSIVE ACID _____________________ I _____________________ MANUALE D ISTRUZIONE Make sure the battery charger is disconnected from the power supply Check the polarities of the battery terminals positive for the symbol and negative for the symbol NOTE if the symbols are indistinguishable remember that the positive terminal is the one not connected to the vehicle chassis Connect the red charge clamp to the positive terminal of the battery symbol Connect the black charge clamp to the vehicle chassis at a safe distance from the battery and the fuel pipe NOTE if the battery is not installed in the vehicle connect the clamp directly to the negative terminal of the battery symbol AM ATTENZIONE PRIMA DI UTILIZZARE IL CARICABATTERIE LEGGERE ATTENTAMENTE IL MANUALE D ISTRUZIONE 1 SICUREZZA GENERALE PER L USO DI QUESTO CARICABATTERIE Durante la carica le batterie emanano gas esplosivi evítate che si formino flamme e scintille NON FUMARE Posizionare le batterie in carica in un luogo areato A CHARGE A Le persone inesperte devono essere l opportunamente istruite prima di utilizzare L l apparecchio Le persone bambin compresi le cul capacità fisiche sensorial mental siano insufficienti ai fini di utilizzare correttamente l apparecchio devono essere sorvegliate da una persona responsabile délia loro sicurezza durante Tuso dello stesso I bambin devono essere sorvegliati per sincerarsi che non giochino con l apparecchio Power the battery charger by inserting the power supply cable into the mains outlet Select the battery type and only for the T CHARGE 20 model the charge voltage using the key shown in fig A 5 Select the charge current using the button shown in fig A 1 During this phase the battery charger will operate keeping the charge current constant END OF CHARGE Disinserire il cavo di alimentazione dalla rete prima di connettere o sconnettere i cavi di carica dalla batteria Non collegare ne scollegare le pinze alla batteria con il caricabatterie funzionante Non usare nel modo più assoluto il caricabatterie all interno di un autovettura o del cofano Sostituire il cavo di alimentazione solo con un cavo originale Non utilizzare il caricabatterie per ricaricare batterie di tipo non ricaricabili Verificare che la tensione di alimentazione disponibile sia corrispondente a quella indicata sulla targa dati del caricabatterie Per non danneggiare l elettronica dei veicoli leggere conservare rispettare scrupolosamente le awertenze fornite dai costruttori dei veicoli stessi quando si utilizza il caricabatterie sia in carica che in avviamento lo stesso vale per le indicazioni fornite dai costruttore di batterie The battery charger indi cates tha t charging h as fini shed by lighting up the green FULL LED fig A 3 Disconnect the power supply to the battery charger by removing the power supply cable from the mains outlet Disconnect the black charge clamp from the chassis of the vehicle or from the negative terminal of the battery symbol Disconnect the red charge clamp from the positive terminal of the battery symbol Store the battery charger in a dry place Close up the battery cells with the appropriate plugs if present 6 BATTERY CHARGER PROTECTIONS The battery charger is equipped with protection in case of Overloads too much current delivered towards the 4
