EN
3.4.3 Welding functions
OTHER PROCESSES (In Edit Channel menu 3/6)
HotStart
ON, OFF or USER Factory setting is USER =>
USER can freely choose is the
HotStart ON or OFF
HOTStartLevel
-50 ... +100 % 1 % steps. Factory setting 40 %
Hot 2T Time
0 – 9.9 s 0.1 s steps. Factory setting 1.2 s
CraterFill
ON, OFF, USER Factory setting is USER =>
USER can freely choose is the
CraterFill ON or OFF
CraterStart
10 – 250 % Factory setting is 100% Set the level of the curve where the crater
lling will start
CraterFillEnd
10 – 250 %
lower than start
1 % steps. Factory setting 30% Set the level of the curve where the crater
lling will end.
CraterTime
0.0 – 10.0 s 0.1 s steps. Factory setting 1.0 s CrateFill Slope Time
Creep Start
10 – 99 % 1% steps. OFF, CURVE
(OFF = 100%)
Factory setting is CURVE (Creep Start value
comes from Welding Curve).
StartPower
-9 ... +9 Factory setting is 0 Adjusts arc ignition
WISEROOT / WISETHIN
HotStart
ON, OFF or USER Factory setting is USER =>
USER can freely choose is the
HotStart ON or OFF
HOTStartLevel
-50 ... +100 % 1 % steps. Factory setting 40 %
Hot 2T Time
0 – 9.9 s 0.1 s steps. Factory setting
1.2 s
CraterFill
ON, OFF, USER Factory setting is USER =>
USER can freely choose is the
CraterFill ON or OFF
CraterStart
10 – 250 % Factory setting is 100% Set the level of the curve where the crater
lling will start.
CraterFillEnd
10 – 250 %
lower than start
1 % steps. Factory setting 30%
CraterTime
0.0 – 10.0 s 0.1 s steps. Factory setting
1. 0 s
Creep Start
10 – 99 % 1% steps. OFF, CURVE
(OFF = 100%)
Factory setting is CURVE (Creep Start value
comes from Welding Curve).
18
KempArc Pulse TCS / © Kemppi Oy / 1204
