3
www.timberk.com electric instant water heater
ENGLISH
. OPERATIONAL CHARACTERISTICS
WATERMASTER I Series. Water Heater Models: WHE 3.5 XTR H1, WHE 4.5
XTR H1, WHE 5.5 XTR H1
1. Instantaneous water heating without preprocessing and waiting.
2. Reliable nichrome spiral heating element with ceramic protection;
the special shape prevents significant accumulation of scale.
3. Automatic temperature protection (electronic temperature sensor)
protects water heater from overheating, and assures user protec-
tion against burns.
4. Hydraulic flow sensor automatically stops the heating mode when
cold water supply is suddenly interrupted or water pressure in the
system drops below the working level.
5. The water heater is designed for household application, for one
water consumption point and can be installed in any convenient
place.
6. Ultra-thin and space-saving design is ideal for installation and use
both in a city apartment, and a country-side house. And quicker
and safer heating combined with notable electric power saving,
which means less costs, will be pleasing you during the whole life-
time of TIMBERK water heater.
WATERMASTER II Series. Water Heater Models: WHE 5.0 XTN Z1, WHE 6.0
XTN Z1, WHE 6.5 XTN Z1, WHE 7.0 XTN Z1, WHE 8.0 XTN Z1
1. Instantaneous water heating without preprocessing and waiting.
2. Reliable nichrome spiral heating element with ceramic protection;
the special shape prevents significant accumulation of scale.
3. Temperature protection (temperature switch) protects water heater
from overheating, and assures user protection against burns.
THE IMPORTANT PRECAUTIONS AND INSTRUCTIONS CONTAINED IN
THIS INSTRUCTION MANUAL DO NOT INCLUDE ALL POSSIBLE MODES
AND SITUATIONS, WHICH MAY OCCUR. IT IS NECESSARY TO
UNDERSTAND THAT COMMON SENSE, CAUTIOUSNESS, AND
CAREFULNESS ARE FACTORS, WHICH CANNOT BE "INTEGRATED" TO
ANY PRODUCT. THESE FACTORS SHALL BE TAKEN INTO ACCOUNT BY
THE PERSON, WHO IS INTERESTED IN PROPER OPERATION OF THE
DEVICE. THE MANUFACTURER IS NOT RESPONSIBLE FOR DAMAGE OF
THE APPLIANCE OR ITS COMPONENTS DURING TRANSPORTATION, AS
A RESULT OF IMPROPER INSTALLATION, DUE TO VOLTAGE SURGES, AS
WELL AS IN THE EVENT OF UNAUTHORIZED CHANGES OR
MODIFICATIONS IN ANY PART OF THE APPLIANCE.
2. PRECAUTIONS
During operation of the water heater, it is necessary to observe some
precautions. Improper operation due to ignorance of the precautions
may result in personal injury of the user or other people, as well as dam-
age of their property.
1. Any electric appliance shall be under observation during its opera-
tion, especially if there are children close by. Carefully watch that
children do not touch the appliance.
2. Before installation and connection of the water heater to the electric
mains, check and make sure that there is a grounding loop in your
electric mains. If there is no grounding loop in your electric mains,
operation of the water heater is hazardous for life.
3. Connect your water heater to the power supply which has the same
parameres as indicated on Rating Label. If it's necessary, ask technical
characteristics of power supply from your electricity' suppliers.
4. Never use the water heater, if it is faulty.
5. Do not remove the front panel of the water heater during its opera-
tion.
6. Immediately disconnect the water heater from the electric mains in
case of strange sounds, odor, or smoke from it.
7. Always disconnect the water heater from the electric mains during
storms.
8. Before beginning of cleaning and maintenance of the water heater,
always disconnect it from the electric mains. Perform cleaning and
maintenance in accordance with the guidelines of this instruction
manual.
9. Do not use hazardous chemicals for cleaning of the water heater and
exclude their contact with it.
10. Do not use the water heater for purposes not specified in this in-
struction manual.
11. Do not use the water heater in explosive or corrosive environment.
Do not store gasoline and other volatile highly inflammable liquids
near the appliance. This is very hazardous!
12. It is prohibited to change the design of the water heater or modify
it.
13. Any service works shall be performed by a specialized organization,
by qualified specialists. Improper installation may result in refusal of
warranty service.
ATTENTION!
The water heater shall be certainly grounded.
