www.timberk.com e instant water heaterlectric
ENGLISH
WHE 5.5 XTR H1
220/50
25,0
5,5
0,1-0,6
3,8
I
IPX4
3x2,5
25
210x120x85
0,8
WHE 3.5 XTR H1
220/50
15,1
3,5
0,1-0,6
2,4
I
IPX4
3x1,5
16
210x120x85
0,8
Characteristic
Rated voltage (alternating)
Rated current
Rated power input
Operating pressure
Capacity (at Δt=20 °)
Electric protection class
Protection degree
Power connection cable (copper)
Automatic circuit breaker
Dimensions
Net weight
Unit
V/Hz
kW
MPa
l/min
-
mm
mm (HWD)
kg
Table 1
Technical Characteristics
Technical characteristics of WATERMASTER I Series water heaters are given in Table 1.
Technical characteristics of WATERMASTER II Series water heaters are given in Table 2.
Model Names
WHE 6.5 XTN Z1
220/50
29,6
6,5
0,1 - 0,6
4,5
I
IP24
3x4
32
172x188x90
1,0
Characteristic
Rated voltage (alternating)
Rated current
Rated power input
Operating pressure
Capacity (at Δt=20 °)
Electric protection class
Protection degree
Power connection cable (copper)
Automatic circuit breaker
Dimensions
Net weight
Unit
V/Hz
kW
MPa
l/min
-
mm
mm HWD
kg
WHE 5.0 XTN Z1
220/50
22,8
5,0
0,1 - 0,6
3,5
I
IP24
3x2,5
25
172x188x90
1,0
WHE 6.0 XTN Z1
220/50
27,3
6,0
0,1 - 0,6
4,2
I
IP24
3x4
32
172x188x90
1,0
Table 2
WHE 7.0 XTN Z1
220/50
31,8
7,0
0,1 - 0,6
4,9
I
IP24
3x4
32
172x188x90
1,0
WHE 8.0 XTN Z1
220/50
36,4
8,0
0,1 - 0,6
5,6
I
IP24
3x6
40
172x188x90
1,0
WHE 4.5 XTR H1
220/50
20,5
4,5
0,1-0,6
3,1
I
IPX4
3x2,5
25
210x120x85
0,8
Model Names
