Selva ANTIBES 30 [23/37] Eliche propellers
![Selva ANTIBES 30 [23/37] Eliche propellers](/views2/1240422/page23/bg17.png)
Pos.
Ref. No
Q.tà
Q.ty
N. Codice
Part No
Denominazione Name of part
73 1 6520215 Albero verticale normale Vertical shaft - normal
73 1 6520195 Albero verticale lungo Vertical shaft - long
73 1 6520325 Albero verticale extra lungo Vertical shaft - extra long
74 1 3570470 Anello OR 34.6 x 2.62 OR ring 34.6 x 2.62
75 1 5570325 Anello ritegno RB 26 Bull ring RB 26
76 1 3550220 Anello tenuta 15 x 26 x 7 Grommet 18 x 28 x 7
77 1 3555115 Anello tenuta RP 15 x 26 x 7 Grommet RP 18 x 28 x 7
79 1 9005640 Lamierino pompa Pump sheet
80 1 5565010 Spina di trascinamento ø 3x11 Impeller pinø 3x11
81 1 8095050 Ventolina pompa Water impeller
82 1 3570320 Anello OR 50.52x1.78 OR ring 50.52x1.78
84 4 5505070 Rondella M5 Washer M5
85 4 4005156 Vite TE M5 x 40 Screw TE M5 x 40
86 1 8045130 Gommino albero verticale Vertical shaft grommet
87 1 3570150 Anello OR 10x2 OR ring 10x2
88 1 8030370 Bussola ritegno OR OR retainer bushing
89 1 6580150 Tubo acqua normale Water pipe - normal
89 1 6580140 Tubo acqua lungo Water pipe - long
89 1 6580145 Tubo acqua extra lungo Water pipe - extra long
91 1 9006290 Separatore di scarico ( Antibes 15 XS ) Exhaust separator ( Antibes 15 XS )
91 1 9006295 Separatore di scarico ( Antibes 20 XS ) Exhaust separator ( Antibes20 XS )
91 1 9006310 Separatore di scarico ( Antibes 25 XS ) Exhaust separator ( Antibes 25 XS )
92 1 7020120 Pernetto inferiore Lower gudgeon
93 1 5505010 Rondella M14 Washer M14
94 1 9035250 Spallamento Shoulder
95 2 8025740 Griglia immissione acqua Cover, water intel
96 2 4505010 Vite autofilettante 3.9 x 9.5 Phillips Self screwing screw 3.9 x 9.5 Phillips
ELICHE PROPELLERS
(complete di parastrappi) (with spring drive)
3 1 2505475 Elica diam.10 1/2”x9" Propeller diam.10 1/2"x9"
1 2505480 Elica diam.10 1/2”x10" Propeller diam.10 1/2"x10"
1 2505500 Elica diam.10 1/2"x11" Propeller diam.10 1/2"x11"
1 2505520 Elica diam.10 1/2"x12" Propeller diam.10 1/2"x12"
1 2505570 Elica diam.10 1/2"x12 1/2" Propeller diam.10 1/2"x12 1/2"
1 2505540 Elica diam.10 1/2"x13" Propeller diam.10 1/2"x13"
1 2505560 Elica diam.10 1/2"x14" Propeller diam.10 1/2"x14"
GRUPPI ASSEMBLIES
12 1 1598291 Tappo scarpetta completo Complete gear box plug
(pos. 6+7+8+12+14) (pos. 6+7+8+12+14)
22 1 1564100 Ingranaggio retromarcia Reverse gear
(pos. 21+22) (pos. 21+22)
26 1 1567010 Albero orizzontale completo Complete horizontal gear
(pos. 26+27+28) (pos. 26+27+28)
29 1 1564095 Ingranaggio marcia avanti Forward gear
(pos. 29+30) (pos. 29+30)
44 1 1568010 Prigioniero cavo completo Complete hollow stud
(pos. 44+45+46+47) (pos. 44+45+46+47)
78 1 1558020 Supporto pompa completo Pump support
(pos. 74+75+76+77+78) (pos. 74+75+76+77+78)
83 1 1560070 Corpo pompa completo Complete pump body
(pos. 82+83+87+88) (pos. 82+83+87+88)
90 1 1569031 Kit anodi Anode kit
1 1557695 Piede normale completo Complete gearcase - normal
1 1557700 Piede lungo completo Complete gearcase - long
1 1557705 Piede extra lungo completo Complete gearcase - extra long
1 1566285 Serie guarnizioni piede Gearcase gasket set
1563180 Triade conica (22+29+66+68) Gear set (22+29+66+68)
