Selva ANTIBES 30 [5/37] Model antibes 15xs 489b antibes 20xs 489a antibes 25xs 489b

TECHNICAL FEATURES

MODEL ANTIBES 15XS – 489B ANTIBES 20XS – 489A ANTIBES 25XS – 489B

POWER 15 HP/11 Kw 20 HP/14,7 Kw 25 HP/18,4 Kw

FULL THROTTLE (RPM) 5000/5500 5000/5500 5000/5500

DISCLACEMENT (cc.) 489 489 489

BORE x STROKE 72x60 72x60 72x60

NUMBER OF CYLINDRES 2 cyl. in line 2 cyl. in line 2 cyl. in line

ENGINE TYPE Otto cycle - 2 stroke

FUEL PUMP N° 1 diaphragm pump Dellorto

CARBURETTORS N° 1 carburettor mod. Dellorto FHE 30/28

AVERAGE CONSUMPTION 7 l/h 8 l/h 9 l/h

FUEL gasoline mixed with 2 stroke outboard oil (TC-WII)

FUEL TANK separated, capacity lt.25

IGNITION electronic, capacitive discharge, waterproof

SPARK ADVANCE electronic, automatic programmed on engine revolution

MANUAL STARTING cord with automatic recovery on pulley (1)

ELECTRIC STARTING Standard with 12V/70W generator and rectifier for battery recharge

SPARK PLUGS BOSCH W3AC-CHAMPION L78HEAT RATING 275

EXHAUST bilateral, underwater, vacuum operated through boss

COOLING forzed water circulation by pump

GEAR RATIO 13/27

SHIFT CONTROL mechanical: Forward-Neutral-Reverse

GEARCASE OIL 80 W/90 (API GL-5 SAE 80 W/90)

GEARCASE OIL QUANTITY 420 cc./385 gr.

PROPELLER TYPE weedless 3 blades with rubber bushing

TRIM METHOD 5 changeable positions with pin

SUSPENSIONS dampers

SHAFT LENGTH (mm) standard shaft 570 - long shaft 695

TRANSOM HEIGHT (mm) standard shaft 380-400 - long shaft 500-520

WEIGHT (Kg) standard shaft Kg 52 - long shaft Kg 54

(1) Generator 12V/70W and rectifier available on request

Selva SpA reserves the right to make changes at any time without notice in weights, material constructions and features without

incurring the obbligation to equip same on models manufactured before the date of such change
