Selva PORTOFINO 80 [21/59] Collo a cerniera tilt bracket tilt assy
![Selva PORTOFINO 80 [21/59] Collo a cerniera tilt bracket tilt assy](/views2/1240431/page21/bg15.png)
COLLO A CERNIERA TILT / BRACKET TILT ASSY
Pos.
Ref. No
Q.tà
Q.ty
N. Codice
Part No
Denominazione Name of part
1 1 2065290 Barra a guida Steering bracket
2 2 4005100 Vite TEM8x20 Screw TE M8x20
3 1 9006040 Piastra attacco timoneria Steering plate
5 2 5505060 Rondella M8 Washer M8
6 2 5550140 Spina elastica diam. 10x50 Pin diam. 10x50
7 1 6590220 Canotto sterzo Steering tube
8 1 9030260 Rasamento canotto Steering tube shim
9 2 3570410 Anello OR 29,82x2,62 OR ring 29,82x2x62
10 2 9060130 Boccola Bushing
11 1 1551200 Collo a cerniera completo di bussole Swivel bracket with bushing
12 1 2070440 Supporto inferiore molleggi Springing lower support
13 1 2080211 Staffa sinistra Left bracket
14 1 2080221 Staffa destra Right bracket
15 2 8000240 Tappo protezione tubo Tube plug
16 2 5080010 Ghiera tubo staffe Bracket tube ring out
17 1 6590210 Tubo staffe Bracket tube
18 2 9025480 Rondella frizione Friction washer
19 2 9060120 Boccola Bushing
20 2 8060330 Cappuccio supporto Support cap
21 1 1598220 Supporto sinistro Left support
22 1 1598230 Supporto destro Right support
23 2 5555020 Spina elastica diam. 3x18 Pin diam. 3x18
24 2 8030141 Bussola snodo cricchetto Bushing joint
25 1 7080150 Eccentrico comando cricchetto Joint eccentric
26 1 8030135 Bussola snodo interna Internal bushing joint
27 1 7010120 Spina aggancio molla Spring pin
28 1 5590630 Molla richiamo Spring
29 4 5590621 Anello di fermo Ring
30 4 9030160 Anello rasamento Ring
31 1 7020790 Perno tilt Tilt pin
32 1 4005040 Vite TE M6x10 Screw TE M6x10
33 1 1572781 Cavetto massa Dead ground
34 2 4005040 Vite TE M6x10 Screw TE M6x10
35 5 5090020 Ingrassatore Greaser screw
36 1 6575160 Spina regolazione Regulation pin
37 1 5050070 Dado M12 autobloccante Selflocking nut M12
38 1 7020810 Perno inferiore pistone tilt Lower tilt piston ring
40 6 8030310 Bussola nylon Nylon bushing
41 1 7545010 Pistone Tilt piston (shock absorber)
42 1 4005040 Vite TE M6x10 Screw TE M6x10
43 1 9010820 Leva comando Throttle lever
44 1 8020210 Cappuccio su leva comando Cup on lever control
45 2 4015260 Vite TCEI M10x40 Screw TCEI M10x40
46 3 5505080 Rondella M6 Washer M6
47 1 7025280 Distanziale staffe Bracket spacer
48 2 4005070 Vite TE M6x20 Screw TE M6x20
49 2 5505080 Rondella M6 Washer M6
50 1 2504015 Anodo Anode
51 2 4005590 Vite TE M12x70 Screw TE M12x70
52 1 8050780 Tubetto per speedmeter Tube for speedmeter
53 4 8060340 Collarino stringitubo Clamp for tube
54 3 8025090 Fascetta stringitubo Clamp
55 2 8055060 Raccordino Connector
56 4 4005020 Vite autof. TC 3,9x9,52 Screw TC 3,9x9,52
57 2 5590680 Anello su spina regolazione Pin Ring
58 1 5050030 Dado autobloccante M8 Selflocking nut M8
59 1 5505060 Rondella M8 Washer M8
60 1 7005340 Vite snodo piastrina timoneria Steering link screw
61 1 7080190 Barra di rinvio Rod steering link
62 1 5505030 Rondella M10 Washer M10
63 1 5505060 Rondella M8 Washer M8
64 1 5050100 Dado autobloccante M8 Selflocking nut M8
65 1 9030261 Rasamento Shim
66 2 4005060 Vite TE M6x12 Screw TE M6x12
67 1 5505070 Rondella M5 Screw M5
68 1 1572781 Cavetto massa ( St.Tropez) Dead ground ( St.Tropez)
68 1 1572780 Cavetto massa ( Tenerife, portofino ) Dead ground ( Tenerife, portofino )
69 1 9005655 Anodo Anode
70 1 4030015 Vite TSEI M6x10 Screw
GRUPPI
ASSEMBLIES
1551230 Gruppo collo cerniera completo di Bracket tilt assy complete with shock
shock absorber ( da pos. 1 a 57+65 ) absorber ( from pos. 1 to pos. 57+65 )
1591010 Kit trasformazione da Tilt a Power Trim Transformation set from Tilt to Power Trim
