Selva PORTOFINO 80 [31/59] Piede gearcase
![Selva PORTOFINO 80 [31/59] Piede gearcase](/views2/1240431/page31/bg1f.png)
PIEDE / GEARCASE
St. Tropez
Pos.
Ref. No
Q.tà
Q.ty
N. Codice
Part No
Denominazione Name of part
1 1 5580090 Copiglia 3,2x25 Split pin
2 1 5040030 Dado esagonale ad intagli Nut, castle
3 1 9025520 Rondella Washer
5 1 7040300 Spallamento interno elica Internal propeller shoulder
6 1 5590650 Anello ritegno Ring
7 1 3555040 Anello di tenuta RP 22x35x6.5 Seal ring RP 22x35x6.5
8 1 3550140 Anello di tenuta 22x35x6 Seal ring 22x35x6
9 2 4010060 Vite TE M8x30 A4 Screw TE M8x30 A4
10 2 5505060 Rondella M8 Washer M8
11 1 2045440 Tappo scarpetta Gear box plug
12 2 3570530 Anello OR 63.22x1.78 OR ring 63.22x1.78
13 1 3570350 Anello OR 71.12x2.62 OR ring 71.12x2.62
14 1 3030010 Cuscinetto a rullini 22x28x20 Needle bearing 22x28x20
15 1 3005170 Cuscinetto a sfere 30x62x16 Ball bearing 30x62x16
16 1 9030250 Rasamento retromarcia Reverse gear shim
17 1 9060100 Bronzina ingranaggio retromarcia Reverse gear bushing
18 1 9020080 Cavallotto U bolt
19 1 5005010 Dado M6 Nut M6
20 1 7020820 Pernetto Pin
21 1 5580010 Copiglia Split pin
24 2 3005260 Sfera Sphere
25 1 5590560 Molla Ring
26 1 5570050 Anello seeger RS 9 Seeger ring RS 9
27 1 6005260 Ingranaggio verticale Vertical gear
28 1 9030440 Rasamento Shim
29 1 9045070 Bilancere Rocker arm
30 1 2510340 Anello scorrimento Ring
31 1 6020180 Cursore Slider
33 1 9060110 Bronzina ingranaggio marcia avanti Forward gear bushing
34 1 9030450 Rasamento marcia avanti Forward gear shim
35 1 3010050 Cuscinetto rulli conici Taper roller bearing
36 1 2095185 Scarpetta Gear box
37 2 7005210 Tappo Plug
38 3 3570160 Anello OR 6.75 x 1.78 OR ring 6.75 x 1.78
39 4 4505010 Vite autofilettante 3.9 x 9.5 Pillips Self screwing screw 3.9 x 9.5 Pillips
40 4 8025740 Griglia immissione acqua Cover, water inlet
41 1 9025210 Guarnizione perno bilancere Gudgeon gasket
42 1 7020780 Perno bilancere Gudgeon
43 4 5560510 Spina riferimento ø 5 x 18 Pinø 5 x 18
44 1 7015240 Prigioniero anteriore M10 Front stud M10
44 1 7015400 Prigioniero anteriore per gambo lungo Front stud M 10 (long shaft)
44 1 7015210 Prigioniero anteriore ( gambo extra lungo ) Front stud M 10 ( extra long shaft )
45 1 3015100 Cuscinetto a rullini 30 x 40 x 30 Needle bearing30 x 40 x 30
46 1 3570050 Anello OR 44.17 x 1.78 OR ring OR 44.17 x 1.78
47 1 3570290 Anello OR 14 x 1.78 OR ring OR 14 x 1.78
48 1 7015271 Prigioniero posteriore Back stud
50 1 3005280 Cuscinetto a sfere 17 x 40 x 12 Ball bearing 17 x 40 x 12
51 2 7030590 Anello sostegno Ring
52 2 3570480 Anello OR 6.4 x 1.9 OR ring 6.4 x 1.9
53 1 7030580 Bussola ritegno Bushing
54 1 2090310 Puntale Push rod
55 2 4010070 Vite TE M8 x 35 Screw TE M8 x 35
56 1 4015175 Vite TCEI M8 x 100 Screw TCEI M8 x 100
57 1 2504020 Anodo Anode
58 1 4005110 Vite TE M6 x 25 Screw TE M6 x 25
59 1 7005220 Tappo Plug
60 1 4015120 Vite TCEI M6 x 16 Vite TCEI M6 x 16
61 1 2500065 Pinna direzionale Propeller skeg
62 1 7030280 Bussola centraggio Bushing
63 1 5505030 Rondella M10 Washer M10
64 1 5005020 Dado M10 Nut M10
65 1 5505010 Rondella M14 Washer M14
66 1 5040010 Dado M14x1,25 Nut M14x1,25
67 1 8025270 Soffietto su asta marce Bellows on gear rod
68 1 5590360 Fascetta Clump
69 1 6530415 Asta inferiore marce Lower gear rod
