TECHNICAL FEATURES
MODEL
St.TROPEZ 40 XS
741A
St.TROPEZ 50 XS
741A
St.TROPEZ 55
741A
POWER 40,8 HP (30 Kw) 50 HP (36,8 Kw) 55 HP (40,5 Kw)
FULL-THROTTLE
OPERATING RANGE (RPM)
5000/5500 5000/5500 5000/5500
DISPLACEMENT (c.c.) 741 741 741
BORExSTROKE 68x68 68x68 68x68
NUMBER OF CYLINDERS 3 cyl. in line
ENGINE TYPE Otto cycle - 2 stroke
FUEL PUMP N° 1 diaphragm pump Dellorto
CARBURETORS
N° 3 Dellorto
OVC 34/30 type
N° 3 Dellorto
OVC 34/30 type
N° 3 Dellorto
OVC 34/30 type
AVERAGE CONSUMPTION 16 litres/hour 17 litres/hour 18 litres/hour
FUEL
Unleaded gasoline- 95 R.O.N. minimum - mixed with 2 stroke outboard oil
( Only unleaded gasoline- 95 R.O.N. minimum – if engine M.A version.)
FUEL TANK separated, capacity 23 litres
ENGINE LUBRICATION 2 stroke synthetic outboard motor oil (TCW-3)
MOTOR OIL TANK Built in, capacity 3 liters ~ (if engine M.A version)
IGNITION marine, electronic, capacitive discharge
SPARK ADVANCE electronic, automatic programmed on engine revolution
ELECTRIC STARTING standard with 12V/70W generator and rectifier for battery recharge (1)
SPARK PLUGS BOSCH W3A - CHAMPION L 78 - heat rating 275
EXHAUST underwater, vacuum through boss
COOLING forzed water circulation by pump
GEAR RATIO 13/27
SHIFT CONTROL Mecanichal: Forward - Neutral - Reverse
GEARCASE OIL API GL-5 SAE 80 W/90 MIL - L 2105 C (SAE 90)
GEARCASE OIL QUANTITY 480 c.c. / 440 gr.
PROPELLER TYPE weedless 3 blades with rubber bushing
TRIM METHOD 5 changeable positions with pin (2)
SUSPENSIONS vibration dampers
TRANSOM HEIGHT (mm.) long shaft 508
WEIGHT OF STANDARD VERSION
( Kg ) abaut
104
(1) Generator 12V/110W for battery recharge available on request
(2) On request power trim-tilt
Selva SpA reserves the right to make changes at any time without notice in weights, material constructions and features without
incurring the obbligation to equip same on models manufactured before the date of such change
