Selva PORTOFINO 80 [7/59] Bacinella capote basin hood
![Selva PORTOFINO 80 [7/59] Bacinella capote basin hood](/views2/1240431/page7/bg7.png)
BACINELLA - CAPOTE / BASIN HOOD
Pos.
Ref. No
Q.tà
Q.ty
N. Codice
Part No
Denominazione Name of part
1 1 2055380 Bacinella Basin
2 1 3530180 Guarnizione bacinella-motore Engine-cover gasket
3 1 2055377 Flangia bacinella Basin flange
4 1 3530191 Guarnizione bacinella-gambo Cover - shaft gasket
5 4 4005070 Vite TE M 6 x 20 Screw TE M 6 x 20
6 4 5050011 Dado autobloccante M6 Self -locking screw M6
7 1 8060430 Passacavo ( modelli con power trim ) Fairlead (models with power trim)
7 1 8000403 Tappo ( modelli senza power trim ) Plug (models without power trim)
8 1 8000340 Fermacavo Fairlead
9 1 8060410 Passacavo cavi telecomando Fairlead cable remote control box
10 1 8065092 Attacco rapido maschio Male fuel connector
11 4 8030050 Bussola Bush
12 2 8015330 Impugnatura gancio capote Handgrip capote hook
13 2 5555061 Spina elastica ø 4 x 18 Elastic plug ø 4 x 18
14 2 1599411 Gancio capote Capote hook
15 1 8000402 Tappo Plug
16 1 8060420 Passacavo cavi elettrici Fairlead electric cables
17 1 9006270 Piastrina su passacavo Plate on fairlead
18 2 4045070 Vite TC Phillips M 5 x 30 Screw TC Phillips M 5 x 30
19 2 4005050 Vite TE M6 x 15 Screw TE M6 x 15
20 2 2510060 Registro supporto rullino Pin register support
21 2 1599430 Supporto rullino completo Complete register support
22 2 5505080 Rondella M6 Washer M6
23 2 5005010 Dado M6 Nut M6
24 1 8010190 Profilo capote Capote profile
25 2 8092605 Decalco " SELVA MARINE " Decal " SELVA MARINE "
26 6 8060360 Cappuccio rivetto Rivet cup
27 6 7065110 Rivetto Rivet
29 2 8092151 Decalco potenza " 40" Decal power " 40"
29 2 8092131 Decalco potenza " 50" Decal power " 50 "
29 2 8092820 Decalco potenza " 55" Decal power " 75"
29 2 8092231 Decalco potenza " 60" Decal power " 60 "
29 2 8092281 Decalco potenza " 70" Decal power " 70"
29 2 8092321 Decalco potenza " 80" Decal power " 80"
30 1 8092261 Decalco laterale sinistra Lateral decal - Left
31 2 8092628 Decalco " St.Tropez " Decal " St.Tropez "
31 2 8092632 Decalco " Portofino " Decal " Portofino"
32 1 8092251 Decalco laterale destra Lateral decal - Right
33 1 4005080 Vite TE M5 x 16 Screw TE M5 x 16
34 1 9006260 Squadretta fissaggio guscio Shell fixing
35 1 8025092 Fascetta Clamp
36 1 9025095 Rondella nylon Nylon washer
37 2 4005090 Vite TE M 5 x 12 Screw TE M 5 x 12
38 4 5050080 Dado autobloccante M5 Self-locking nut M5
39 4 4005140 Vite TE M5 x 20 Inox Screw TE M5x20 Inox
40 2 8025690 Cavallotto fermo guaina Sheat bolt retainer
41 1 9006250 Supporto fermi guaina telecomando Support sheat bolt retainers
42 2 8091191 Decalco " XS " Decal "XS"
43 2 8092880 Decalco “Multipoint autolube” Decal “Multipoint Autolube"
44 1 8000400 Tappo Plug
45 1 8055140 Piastrina aggancio fascetta ( M.A. ) Clamp plate
46 1 8025090 Fascetta (M.A.) Clamp (M.A.)
47 1 1610010 Rivestimento interno capote Hood lining
48 1 4505050
Vite TC Phillips 3,5 x 6,5 autofilettante Screw TC Phillips 3,5 x 6,5
49 1 8055130 Fascetta imperdibilità tappo Cover clamp
50 1 4505010
Vite TC Phillips 3,9 x 9,5 autofilettante Screw TC Phillips 3,9 x 9,5
51 1 3540310 Guarnizione tappo capote Hood cover gasket
52 1 3540320 Guarnizione antifrizione tappo capote Anti-friction gasket
53 1 8000480 Tappo capote Hood cover
54 1 9025091 Rondella nylon Nylon washer
55 1 9025085 Rondella nylon Nylon washer
56 1 8092867 Decalco " 2 Tempi " Decal " 2 Tempi"
